25
DISASSEMBLY AND REASSEMBLY
Evaporator In
Refrigerator
Part Name How To Do Descriptive Picture
4. Remove the housing cover by
pushing both lateral sides of the
housing cover and pulling it out.
(Refer to the picture)
5. Disconnect the housing
connector part. (Refer to the
picture)
6. Remove the evaporator by
Lifting the bottom side of it up
and pulling it out. (Refer to the
picture)
To Next Page
