English - 15
01 SETTING UP
3
1
2
3
4
When you turn the hex wrench counter-
clockwise ( ), the door will move up.
4. After adjusting the doors, please insert the
supplied fastener ( 6 ) using a pliers ( 5 ) in
the gap between the hinge-grommet ( 7 ) and
the lower hinge ( 8 ). The number of fasteners
you’ll need to insert depends on the gap.
2 fastener are enclosed with the
refrigerator.
The thickness of each fastener is 0.04”.
WARNING
• Children should be supervised to ensure that
they do not play with the fastener.
- There is a risk of death from suocation if a
child swallows the fastener.
Pay special attention to children because it can
be dangerous.
Keep the fastener out of reach of children.
INSTALLING THE WATER
DISPENSER LINE
A water dispenser with a fi lter is one of the helpful
features on your new refrigerator. To help promote
better health, the water fi lter removes unwanted
particles from your water. However, it does not
sterilize the water or destroy microorganisms. You
may need to purchase a water purifying system to
do that.
The water line also connects to the ice maker.
For the ice maker to operate properly, water
pressure of 20-125 psi (138 ~ 862 kPa) is
required.
If the refrigerator is installed in an area with low
water pressure (below 20 psi), you can install
a booster pump to compensate for the low
pressure.
After you have connected the water line, make
sure the water storage tank inside the refrigerator
is properly fi lled. To do this, press the water
dispenser lever until the water runs from the water
outlet.
Water line installation kits are available at
extra cost from your dealer.
We recommend using a water line
installation kit that contains copper tubing
and a ¼” compression nut.
Connecting to the water supply line
1. First, shut o the main water supply.
2. Locate the nearest cold water drinking line and
install the pipe clamp and shut o valve.
To Next Page
