11
2-2) Specifications
PRODUCT SPECIFICATIONS
Defrost Control From 24 to 32 hrs
Thermo Bimetal Protector 140°F(60
)(off) 104°F(40 )(on)
Defrost Thermistor(502AT) 50°F(10
)(off)
Electrical Rating AC115V 60Hz 11.6 Amps / 220V~240V 50Hz
Maximum Current Leakage 0.25 mA
Maximum Ground Path Resistance 0.1 Ohm
Energy Consumption 570KWh/year
Ambient Temperature 70
℉(21 ) 90℉(32 )
Refrigerator,℉ 34℉(1 )∼46℉(8 ) 34℉(1 )∼46℉(8 )
Freezer,℉ -14℉(-26
)∼8℉(-13 ) -14℉(-26 )∼8℉(-13 )
Run Time,% 40 60
Refrigerant Charge (R134a) 5.64 oz(160g)
Compressor((MK172D-R2U) 897 Btu/hr(0.263kw)
Compressor oil Freol α-10
Capillary tube(Dia, Length) 0.032
＂＂
,118
＂＂((00..8811mmmm,,22999977mmmm))
Dryer Molecular Sieve XH-9
Clearance must be provided for air circulation
AT TOP 1
＂＂ ((2255mmmm))
AT SIDES 0.5
＂＂ ((1155mmmm))
AT REAR 1
＂＂ ((2255mmmm))
