Samsung RF267AARS - 3-14) Motor Damper; 3-15) Water Filter (Disassembly)

33
DISASSEMBLY AND REASSEMBLY
3-14) Motor Damper
3-15) Water Filter (Disassembly)
Motor Damper
Part Name How To Do Descriptive Picture
1. Remove the cool select pantry.
Remove the screw part of lower
motor damper part and then
push the motor damper down.
2. Disengage 2 housing
connectors from the rear motor
damper.
(Refer to the picture)
Water Filter
Part Name How To Do Descriptive Picture
1. Remove the shelf by lifting the
front plane of the shelf up and
pulling it out.
2. Remove the water filter by
turning it clockwise.
(Refer to the picture)
