26
DISASSEMBLY AND REASSEMBLY
Cover-display
Part Name How To Do Descriptive Picture
4. Remove 4 screws of cover-
display
3-6) Water-dispenser
Water-dispenser
Part Name How To Do Descriptive Picture
1. Disengage the 3 Housing
Connect.
2. Remove 2 screws of the
CaseIce,Route Assy.
3. Pull the Case-Ice,Route Assy.
4. Push the hook and remove the
Micro Switch.
AW-SEM Transform(RF267,2#3957D8 2009.8.20 4:51 PM 페 이 지 2 6 i n

Samsung RF267AE series Specifications

General

Refrigerator Capacity	17.5 cu. ft.
Ice Maker	Yes
Water Dispenser	Yes
Energy Star Certified	Yes
Cooling System	Twin Cooling Plus
Type	French Door
Width	35.75 inches
Color	Stainless Steel
