silver welding rod soldering
silver welding rod soldering
flash soldering (aluminium/braze)
5
5. COOLING SYSTEM CYCLE WORKFOLW
HOT-PIPE
EVAP-REF,ASS'Y
ACCUMULATOR
R CAPILARY
EVAP-FRE ASS'Y
PIPE CLUSTER,L
DRYER
PIPE-SUCT CONNECT
COMPRESSOR
PIPE-DISCHARGE
ASSY VALVE BISTABLE
PIPE CONDENSER,R
F CAPILARY
