Condenser
8-3) Additional information (Cool Cycle Diagram)
Compressor Hot Pipe
Dryer
Capillary Tube
Freezer Evaporator
Suction Pipe
Compressor
Freezer Evaporator
Accumulator
Dryer
Hot Pipe
Compressor
Capillary Tube
Condenser
Suction Pipe
Muffler
Hot Pipe
