3-3) Freezer Micro Switch
1. After disassembling Freezer Display,
remove 1 screw.
PART NAME FIGURE
Freezer
Micro S/W
DESCRIPTION
2. Unlock the hook using flat head screwdriver.
3. Pull out Lever Assembly.
4. Disconnect Micro S/W as shown.
25
DISASSEMBLY & REASSEMBLY
Be careful of injury.
