7. Remove Upper Hinge with handing Wires
PART NAME FIGURE
Freezer
Door
DESCRIPTION
8. Lift up Freezer Door , let pipe get out of hinge
hole carefully and take door out.(optional)
27
DISASSEMBLY & REASSEMBLY
3-5) Freezer Compartments
1 . Lift up Tray Dispenser with grabbing.(optional)
PART NAME FIGURE
Tray
Dispenser
Door Bins
DESCRIPTION
1. The door bins allow storage of perishable
items.
2. Lift the bin up and slide it out.
Be careful not to scratch.
Be careful not to scratch.
Be careful of injury.
Be careful of injury.
