Samsung RSA1J Series Service Manual

75
Parts List of Fridge
(RSA1D RSA1U RSA1N RSA1S)
NO CODE NO PART NAME Specification Quantit
y
RemarkElectric Part
1
DA97-06007
A
ASSY SHELF REF-HIGH 3
1-1
DA67-01905
A
SHELF REF-HIGH HIPS 1
1-2
DA64-02457
A
GLASS-SHELF REF HIGH GLASS,T3.2 1
2
DA97-06009
A
ASSY SHELF REF-LOW 2
2-1
DA67-01906
A
SHELF REF-LOW HIPS 1
2-2
DA64-02456
A
GLASS-SHELF REF LOW GLASS,T3.2 1
3
DA63-04054
A
COVER VEG-HUMIDITY GPPS 1
4
DA97-06063
A
ASSY CASE VEG-HIGH 1
4-1
DA61-04037
A
CASE-VEG HIGH PP 1
4-2
DA63-04036
A
COVER VEG-FRONT HIGH
B
HIPS 1
4-3
DA63-04037
A
COVER VEG-FRONT HIGH
A
SAN 1
5
DA97-04793
A
ASSY RAIL-LOW L 2
5-1
DA61-03078
A
RAIL-LOW L HIPS
,
-
,
W28
,
L220
,
CO
O
1
5-2
DA66-00420
A
ROLLER-RAIL LOW POM
,
OD22
,
H10
,
NTR
,-
1
6
DA97-04794
A
ASSY RAIL-LOW R 2
6-1
DA61-03079
A
RAIL-LOW R HIPS
,
T2.5
,
W28
,
L220
,C
1
6-2
DA66-00420
A
ROLLER-RAIL LOW POM
,
OD22
,
H10
,
NTR
,-
1
7
DA63-04053
A
COVER VEG-HIGH HIPS 1
8
DA97-06064
A
ASSY CASE VEG-LOW 1
8-1
DA61-04036
A
CASE-VEG LOW PP 1
8-2
DA63-04029
A
COVER VEG-FRONT LOW
B
HIPS 1
8-3
DA63-04031
A
COVER VEG-FRONT LOW
A
SAN 1
10
DA97-05786
A
ASSY TANK WATER 1
RSA1D
RSA1U
9
DA67-01888
A
SHELF-WINE HIPS 1
11
DA63-01077
B
COVER-PURIFIER PP,C 1
12
DA97-06071
A
ASSY COVER DAMPER-REF 1 YES
12-1
DA61-04035
A
CASE DAMPER-REF PP,SC-9343 1
12-2
DA47-00043
H
MOTOR DC-MOTOR-DAMP
E
DC 12V,Max 6 1 YES
12-3
DA32-00024
E
SENSOR TEMP PX-41C 1 YES
12-4
DA47-00274
B
LAMP HOLDER E27,4A 1 YES
12-5
DA62-01722
A
INSULATION-DAMPER REF FOAM-PS 1
12-6
DA62-01721
A
INSULATION-DAMPER REF FOAM-PS 1
12-7
DA72-00583
G
SEAL CUTT OJC 3000
,
T5
,
W40
,
L1
0
0.0134
12-8
DA62-01813
A
SEAL-DAMPER REF EPDM,T10 1
12-9
DA63-04039
A
COVER LAMP-REF PP 1
12
-
10
4713-001206
LAMP-INCANDESCENT
230V, 40W
1YES
120V, 40W
4713-001201
