DISASSEMBLY & REASSEMBLY
3-2. Disassembling the Freezer
PART NAME DESCRIPTION FIGURE
Removing
the Freezer Door
neht dna ,ppU egniH-paC eht evomeR .1
unscrew the 1 screw of Cover-Hinge.
2. Disconnect the connector of wires.
ot gninrut yb swercs egnih evomeR .3
counterclockwise, and then take o the
Hinge-Upp.
Take care when removing the door to ensure
that it does not fall on you.
(If It don't have Display, not exist Cover-
hinge)
yb egnih elddim eht morf rood eht evomeR .4
carefully lifting the door.
5. To re-assembly the freezer doors follow the
reverse steps 4 through 1
[Caution] Be careful not to scratch.
CAUTION
When disassembling, make sure the
unit turned o If you want to assembly,
follow the reverse order
