DISASSEMBLY & REASSEMBLY
PART NAME DESCRIPTION FIGURE
Removing
the Refrigerator
Door
1. First of all disassembly the Freezer Door.
Remove screw and take o the cover.
ylbmessasiD dna rotcennoc eriw eht tcennocsiD .2
Hose.
CAUTION
CAUTION
When assembling the Water Line
Before disconnect the wires be sure
the water tank is empty.
and the Fitting Tube, the Water Hose
needs to be pushed all the way to the
center of the transparent Fitting Tube
to prevent water leak.
Water Line (Hose)
Center of transparent coupler (Fitting)
.rotaregirfeR eht nepO .3
Remove hinge screws by turning to
counterclockwise, and then take o the
Hinge-Mid.
yb egnih wol eht morf rood eht evomeR .4
carefully lifting the door.
CAUTION
Take care when removing the door to
ensure that it does not fall on you.
CAUTION
When disassembling, make sure the
unit turned o If you want to assembly,
follow the reverse order
