DISASSEMBLY & REASSEMBLY
3-10. Disassembling the Cover Evap (RT32, RT36)
PART NAME DESCRIPTION FIGURE
Cover Evap
(RT32, RT36)
1. Remove the cap-screws.
2. Remove 2 screws at the top.
3. Pull out the ribs of air hole with long nose
plier as a picture.
4. Pull out put your finger on the air hole
(Pull it forward and press it down at the same
time)
5. Disconnect the wire harness at the top-left
corner.
To Next Page
