Samsung RT40MA - Voltage Detector

28
3-3V VOLTAGE DETECTOR
The KA7533 prevents error of system from supply
voltage below normal voltage level at the time
power on and instantane ous power off in systems.
n
FEATURES
󳢯Detecting against error operations at the
power ON/OFF
󳢯Resetting function for the low voltage
microprocessor.
󳢯Checking low battery.
■
ORDERING INFORMATION
BLOCK DIAGRAM
Vcc
(
INPUT
)
GND
V
REF
VO
TO-92
1:Input 2:GND 3:Output
Device Package Operating Temperature
KA7533Z TO-92
-30 ~ +75℃
