44
10-1 COVER-EVAP ASS’Y
10. How to Disassemble of freezing Compartment
1. Take out food & useless in the freezer room and get rid of the moisture in the freezer.
2. Please pull up the top with a long-nose and insert the hand into the gab, as shown
below.
Take a part the connected housing.
3. When the COVER-EVAP, ASSY is taken a part, take an action on the problem.
Reassemble the cover evap a’ssy.
To Next Page
