Samsung Electronics 1-9
Exploded View and Parts List
Loc. No New Part No Description and Specification Remark
701 AD97-06158A ASSY-LCD BOARD;DELTA(PVI2.5” LCD),NTSC 2.5” NTSC only
701 AD97-06545A ASSY-LCD BOARD;DELTA(PVI2.5” LCD),PAL 2.5” PAL only
701 AD97-06519A ASSY-LCD BOARD;DELTA(PVI3.5” LCD),NTSC 3.5” NTSC only
701 AD97-06546A ASSY-LCD BOARD;DELTA(PVI3.5” LCD),PAL 3.5” PAL only
703 AD97-04556A ASSY-BL;-,BETA-PJ,2.5”,3T,RGBLU25 2.5” only
703 AD97-06358A ASSY-BL;-,3.5”, 3.5” only
705 AD63-00396A COVER-HINGE BOTTOM 2.5”;DELTA-PJ,ABS 94V 2.5” only
705 AD63-00397A COVER-HINGE BOTTOM 3.5”;DELTA-PJ,ABS 94V 3.5” only
706 AD63-00398A COVER-HINGE TOP 2.5”;DELTA-PJ,ABS 94V0,- 2.5” only
706 AD63-00399A COVER-HINGE TOP 3.5”;DELTA-PJ,ABS 94V0,- 3.5” only
708 AD64-00959A KNOB-LCD 2.5”;DELTA-PJ,ABS 94V0,-,-,-,-, 2.5” only
708 AD64-00960A KNOB-LCD 3.5”;DELTA-PJ,ABS 94V0,-,-,-,-, 3.5” only
709 AD61-01172A HOLDER-LCD 2.5”;DELTA-PJ,POM,-,-,-,-,- 2.5” only
709 AD61-01173A HOLDER-LCD 3.5”;DELTA-PJ,POM,-,-,-,-,- 3.5” only
710 AD61-12033A BRACKET-NUT;SV-D10,T0.8,-,-,-,-,T0.8
711 AD61-01207A BRACKET-NUT;DELTA-PJ,SECC,T0.8,4,4,,M1.4
712 AD61-01132A CASE-LCD BOTTOM (PVI2.5”);DELTA-PJ,ABS 94 2.5” only
712 AD61-01134A CASE-LCD BOTTOM (PVI3.5”);DELTA-PJ,ABS 94 3.5” only
714 AD97-06065A ASSY-HINGE;-,DELTA-PJ,ASSY-HINGE
715 AD97-06489A ASSY-LCD FPC;.,DELTA-PJ,LCD FPC 2.5” only
715 AD97-06668A ASSY-LCD FPC;.,DELTA-PJ,LCD FPC 3.5” only
716 AD07-00030A LCD;PA025XS5-DVC,D4-PJ,-,61.6*49.3 2.5” only
716 AD07-00034A LCD;PA035XS2 3.5” only
717 AD61-01206A SPRING ETC-LCD;DELTA-PJ,SUS304,WPB,,,OD4
718 AD64-01040A INLAY-MS 2.5”;DELTA-PJ,PC,T0.65,W12,
720 AD97-07208A ASSY-CASE LCD TOP 2.5” MS(O) NTSC only
720 AD97-07208B ASSY-CASE LCD TOP 2.5” MS(O)
720 AD97-07208C ASSY-CASE LCD TOP 2.5” MS(O) PAL only
720 AD97-07208D ASSY-CASE LCD TOP 2.5” MS(X) NTSC only
720 AD97-07208E ASSY-CASE LCD TOP 2.5” MS(X)
720 AD97-07208F ASSY-CASE LCD TOP 2.5” MS(X) PAL only
721 AD62-00027A INSULATION-BACK LIGHT;BETA-PJ,PVC,-,-,-, 2.5” only
721 AD62-00030A INSULATION-BACK LIGHT;BETA-PJ,PVC,-,-,-, 3.5” only
902 AC60-10028A SCREW-MACHINE;-,-,ZPC,FE,+,M1.7,-,X3,-,-
903 AC60-12128A SCREW-TAP TITE BH;-,-,-,FE,BH,4 1.7,l4,-
904 AC60-12128B SCREW-TAPTITE;-,-,1.7,4,BH,-,TAP,1.7,-,-
908 6003-001291 SCREW-TAPTITE;CH,+,B,M1.4,L3.0,ZPC(BLK),
913 6001-001545 SCREW-MACHINE;PH,+,M1.4,L3.0,ZPC(WHT),SW
914 6001-001659 SCREW-MACHINE;CH,+,M1.7,L2.5,NI PLT,SWRC
915 6003-001143 SCREW-TAPTITE;PH,+,B,M1.7,L6,NI PLT,SWRC
917 AD60-00002A SCREW MACHINE;-,-,-,-,-,-,-,A3-PJ,-,M2X4
To Next Page
