Samsung Electronics 1-19
Exploded View and Parts List
Loc. No New Part No Description and Specification Remark
301 AD97-06066A ASSY-LINK;-,DELTA-PJ,-
302 AD97-06499A ASSY-START/STOP;DVC,SC-D23,POWER
303 AD97-06487A ASSY-JACK;.,DELTA-PJ,ASSY JACK
306 AD97-06481A ASSY-CASE RIGHT;.,DELTA-PJ,EXP
307 AD61-01169A SPRING ETC-PLATE RECORD;DELTA-PJ,SUS 1/2
308 AD61-60521A SPRING-REC;SC-80,SWPB,4.3,-,-,-,-,-,-,-,
309 AD61-01116A BRACKET-RIGHT;DELTA-PJ,SUS,T0.8,-,-,-,-
311 AD61-60601A SPRING-KNOB POWER;-,SUS304 WPB,-,-,-,-,-
312 AD63-00402A COVER-JACK;DELTA-PJ,TPH,-,-,-,-,-,-,-
313 AD64-00936A BUTTON-POWER RECORD;DELTA-PJ,ABS 94HB,-,
316 AD64-00942A KNOB-POWER;DELTA-PJ,ABS 94HB,-,-,-,-,BLK
317 AD61-01146A PLATE-POWER;DELTA-PJ,SUS T0.5,T0.2,-,-,-
318 AD64-00947A LOCKER-SAFETY POWER;DELTA-PJ,ABS 94HB,-,
319 AD66-00190A SLIDER-POWER;DELTA-PJ,POM,-,-,-,NAT,-
320 AD73-00006A RUBBER—GUIDE DECK;BUTHYL RUB,-,VP-D50,-
321 AD61-12033A BRACKET-NUT;SV-D10,T0.8,-,-,-,-,T0.8
323 AD97-06064A ASSY-BELT GRIP;LEATHER,DELTA-PJ,-
325 3809-001448 FPC CABLE FLAT, 24P
902 AC60-10028A SCREW-MACHINE;-,-,ZPC,FE,+,M1.7,-,X3,-,-
907 6002-001085 SCREW-TAPPING;CH,+,2,M1.7,L5,ZPC(BLK),SW
918 AD60-10509A SCREW-TAP TITE;-,FE-ZN,M2X5,5,PWH,+,-,-,
To Next Page
