Samsung Electronics 2-5
Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
L915 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
L917 2703-001865 INDUCTOR-SMD;33UH,20%,6X6X2.8MM
L918 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
L919 2703-001867 INDUCTOR-SMD;1UH,20%,2.5X2X1.8MM
L922 2703-001865 INDUCTOR-SMD;33UH,20%,6X6X2.8MM
L924 2703-001863 INDUCTOR-SMD;6.8UH,20%,2.5X2X1.8MM
L925 2703-001863 INDUCTOR-SMD;6.8UH,20%,2.5X2X1.8MM
L926 2703-001863 INDUCTOR-SMD;6.8UH,20%,2.5X2X1.8MM
L928 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L929 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L930 2703-001865 INDUCTOR-SMD;33UH,20%,6X6X2.8MM
L934 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L940 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L941 2703-001863 INDUCTOR-SMD;6.8UH,20%,2.5X2X1.8MM
L950 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
LA01 2703-001863 INDUCTOR-SMD;6.8UH,20%,2.5X2X1.8MM
LA02 2703-001883 INDUCTOR-SMD;22uH,10%,2.5x2x1.8mm
LA03 2703-001863 INDUCTOR-SMD;6.8UH,20%,2.5X2X1.8MM
LA05 2703-001863 INDUCTOR-SMD;6.8UH,20%,2.5X2X1.8MM
LA06 2703-001863 INDUCTOR-SMD;6.8UH,20%,2.5X2X1.8MM
LP01 2703-001883 INDUCTOR-SMD;22uH,10%,2.5x2x1.8mm
LP02 2703-001883 INDUCTOR-SMD;22uH,10%,2.5x2x1.8mm
LP03 2703-002174 INDUCTOR-SMD;10UH,10%,2.5X2.0X1.8MM
LP04 2703-002174 INDUCTOR-SMD;10UH,10%,2.5X2.0X1.8MM
LP05 2703-002174 INDUCTOR-SMD;10UH,10%,2.5X2.0X1.8MM
LP06 2703-002174 INDUCTOR-SMD;10UH,10%,2.5X2.0X1.8MM
MD04 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
Q111 0501-002128 TR-SMALL SIGNAL;KTC4075,NPN,100mW,USM,TP
Q112 0501-002128 TR-SMALL SIGNAL;KTC4075,NPN,100mW,USM,TP
Q301 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT-
Q302 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT-
Q401 0501-002374 TR-SMALL SIGNAL;EMZ1,NPN/PNP,150MW,EMT6,
Q402 0501-002374 TR-SMALL SIGNAL;EMZ1,NPN/PNP,150MW,EMT6,
Q403 0501-002374 TR-SMALL SIGNAL;EMZ1,NPN/PNP,150MW,EMT6,
Q404 0504-000168 TR-DIGITAL;RN1104,NPN,100MW,47K/47K,SSM,
Q601 0504-000167 TR-DIGITAL;RN1102,NPN,100MW,10K/10K,SSM,
Q604 0504-000167 TR-DIGITAL;RN1102,NPN,100MW,10K/10K,SSM,
Q605 0501-000172 TR-SMALL SIGNAL;2SB1121,PNP,500mW,PCP,TP
Q701 0501-000552 TR-SMALL SIGNAL;2SA1774-Q,PNP,150mW,EM3,
Q901 0505-001646 FET-SILICON;MCH5803,N,30V,1.4A,370MOHM,0
Q906 0505-001725 FET-SILICON;MCH5818,P,-12V,-1.5A,200MOHM
Q907 0505-001725 FET-SILICON;MCH5818,P,-12V,-1.5A,200MOHM
Q908 0505-001725 FET-SILICON;MCH5818,P,-12V,-1.5A,200MOHM
Q909 0505-001725 FET-SILICON;MCH5818,P,-12V,-1.5A,200MOHM
Q910 0505-001725 FET-SILICON;MCH5818,P,-12V,-1.5A,200MOHM
ICA02 1105-001424 IC-DRAM;K4S643232E,4X512KX32BIT,TSOP(I
ICA03 1107-001365 IC-FLASH MEMORY;K8D1616UBA,1MX16BIT,TBGA
ICA04 0801-002349 IC-CMOS LOGIC;7S66,BILATERAL SWITCH,SOP,
ICP01 1003-001065 IC-CLOCK DRIVER;KS7221D,SOP,20P,225MIL,Q
ICP02 1002-001270 IC-A/D CONVERTER;TLV990BPFB,10,TQFP,48P,
ICP03 1003-001530 IC-MOTOR DRIVER;UPD16877MA-6A5,TSSOP,24P
ICP05 1201-001667 IC-OP AMP;12902,SSOP,TP,14P,173MIL,QUAD,
ICP06 0801-002417 IC-CMOS LOGIC;7SHU04,INVERTER,SSOP,5P,49
ICP07 0801-002417 IC-CMOS LOGIC;7SHU04,INVERTER,SSOP,5P,49
ICP08 AC14-12012T IC-OP AMP;TA75S01F(TE85L),QFP,-
J501 3722-001967 JACK-IEEE1394;4P,-,AU,,-
L112 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
L113 2703-002174 INDUCTOR-SMD;10UH,10%,2.5X2.0X1.8MM
L203 2703-002174 INDUCTOR-SMD;10UH,10%,2.5X2.0X1.8MM
L204 2703-002174 INDUCTOR-SMD;10UH,10%,2.5X2.0X1.8MM
L205 2703-002174 INDUCTOR-SMD;10UH,10%,2.5X2.0X1.8MM
L206 2007-000643 R-CHIP;270ohm,5%,1/16W,DA,TP,1608
L303 2703-000396 INDUCTOR-SMD;10uH,10%,2.5x2x1.8mm
L304 2703-000396 INDUCTOR-SMD;10uH,10%,2.5x2x1.8mm
L305 2703-000396 INDUCTOR-SMD;10uH,10%,2.5x2x1.8mm
L401 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
L501 2703-002174 INDUCTOR-SMD;10UH,10%,2.5X2.0X1.8MM
L502 2703-002174 INDUCTOR-SMD;10UH,10%,2.5X2.0X1.8MM
L601 2703-000396 INDUCTOR-SMD;10uH,10%,2.5x2x1.8mm
L701 2703-000396 INDUCTOR-SMD;10uH,10%,2.5x2x1.8mm
L702 2703-000396 INDUCTOR-SMD;10uH,10%,2.5x2x1.8mm
L801 2703-000396 INDUCTOR-SMD;10uH,10%,2.5x2x1.8mm
L802 2703-002175 INDUCTOR-SMD;100UH,10%,2.5X2.0X1.8MM
L803 2703-000396 INDUCTOR-SMD;10uH,10%,2.5x2x1.8mm
L804 2703-000396 INDUCTOR-SMD;10uH,10%,2.5x2x1.8mm
L805 2703-001867 INDUCTOR-SMD;1UH,20%,2.5X2X1.8MM
L806 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L807 2703-001867 INDUCTOR-SMD;1UH,20%,2.5X2X1.8MM
L808 2703-001867 INDUCTOR-SMD;1UH,20%,2.5X2X1.8MM
L902 2703-000408 INDUCTOR-SMD;3.3uH,20%,3.2x2.5x2.2mm
L903 2703-002570 INDUCTOR-SMD;33UH,20%,4.0X4.0X1.9MM
L904 2703-000375 INDUCTOR-SMD;82uH,5%,2.5x2x1.8mm
L905 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L906 2703-001865 INDUCTOR-SMD;33UH,20%,6X6X2.8MM
L907 2703-001910 INDUCTOR-SMD;68uH,20%,6x6x2.8mm
L908 2703-001910 INDUCTOR-SMD;68uH,20%,6x6x2.8mm
L909 2703-000408 INDUCTOR-SMD;3.3uH,20%,3.2x2.5x2.2mm
L910 2703-001865 INDUCTOR-SMD;33UH,20%,6X6X2.8MM
L913 2703-001863 INDUCTOR-SMD;6.8UH,20%,2.5X2X1.8MM
L914 2703-001863 INDUCTOR-SMD;6.8UH,20%,2.5X2X1.8MM
