Samsung Electronics 1-3
Exploded View and Parts List
Loc. No New Part No Description and Specification Remark
165 AD97-04896A ASSY-DECK;-,CSM2000,ALPA,BETA
160 AD97-05140A ASSY-LENS;-,DVC10X,SUML
161 AD29-00019A FILTER-OPTICAL LPF;-,VP-D73,-,-,3.4X4.5X
170 AD61-01114A BRACKET-LENS;DELTA-PJ,SUS304 1/2H,T0.5,-
171 AD60-00053A SPACER-CCD;ALPHA_PJ,SILICON,-,-,-,BLK,-,
180 AD97-06418A ASSY-CCD;DELTA-PJ, NTSC NTSC only
180 AD97-06417A ASSY-CCD;DELTA-PJ, PAL PAL only
185 AD63-00414A SHIELD-CASE P/AMP;DELTA-PJ,SUS T0.2,-,-,
902 AC60-10028A SCREW-MACHINE;-,-,ZPC,FE,+,M1.7,-,X3,-,-
903 AC60-12128A SCREW-TAP TITE BH;-,-,-,FE,BH,4 1.7,l4,-
190 AD97-06527E ASSY-MAIN BOARD SC-D20
190 AD97-06527A ASSY-MAIN BOARD SC-D21
190 AD97-06527F ASSY-MAIN BOARD SC-D22
190 AD97-06617A ASSY-MAIN BOARD SC-D23
190 AD97-06527B ASSY-MAIN BOARD SC-D24
190 AD97-06527C ASSY-MAIN BOARD SC-D27
190 AD97-06527D ASSY-MAIN BOARD SC-D29
