Exploded View and Parts List
Loc. No New Part No Description and Specification Remark
801 AD61-12033A BRACKET-NUT;SV-D10,T0.8,-,-,-,-,T0.8
803 AD61-01130A CASE-EVF TOP;DELTA-PJ,ABS 94V0 VE0812,-,
804 AD61-01129A CASE-EVF BOTTOM;DELTA-PJ,ABS 94V0 VE0812
805 AD73-00088A RUBBER-EYE CUP;DELTA-PJ,SILICON,-,-,-,D/
806 AD61-01145A GUIDE-LINK;DELTA-PJ,PC ,-,-,-,-
807 AD61-01113A HOLDER-EVF LENS;DELTA-PJ,ABS 94HB BLK,-,
808 AD67-00194A LENS-EVF 14X G1;DELTA-PJ,OPT PLASTIC PMM
809 AD64-00939A KNOB-EVF;DELTA-PJ,POM 94HB BLK,-,-,-,-,
811 AD97-06450A ASSY-LINK EVF;,DELTA-PJ,
812 AD41-00374A FPC-EVF;DELTA-PJ,-,POLYMIDE,-,0.3T
813 AD41-00373A FPC-CVF;DELTA-PJ
902 AC60-10028A SCREW-MACHINE;-,-,ZPC,FE,+,M1.7,-,X3,-,-
931 6003-001142 SCREW-TAPTITE;CH,+,B,M1.7,L5,NI PLT,SRWC
933 AD97-07160A ASSY-UNIT-EVF;0.24NTSC,DELTA-PJ,UNIT-EV NTSC EVF only
933 AD97-07159A ASSY-UNIT-EVF;0.24PAL,DELTA-PJ,UNIT-EV PAL EVF only
934 AD97-06484A ASSY-UNIT-CVF;0.24,DELTA-PJ,UNIT-CV CVF only
936 AD07-00009A LCD-PANNEL;-,MCVVQ410(320),VP-D50,0.24IN EVF only
935 AD97-06506A ASSY-EVF BOARD;DVC,SC-D23,EVF BOARD EVF only
937 AD97-06616A ASSY-CVF BOARD;DVC CVF only
938 AD07-00035A LCD-PANNEL;-,LCX042AK CVF only
