Samsung SCL520 - Page 101

Samsung Electronics6-16
Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
CD08 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CD09 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CD10 2404-001131 C-TA,CHIP;22UF,10%,10V,GP,TP,3528
CD11 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CD12 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
CN001 3708-001345 CONNECTOR-FPC/FC/PIC;11P,-,SMD-A,SN
CN501 3708-001471 CONNECTOR-FPC/FC/PIC;43P,0.5mm,SMD-A,SN
CN601 3710-000554 CONNECTOR-SOCKET;40P,2R,0.8mm,SMD-A,SN
CN602 3708-001472 CONNECTOR-FPC/FC/PIC;36P,0.5mm,SMD-A,SN
CN701 3711-000556 CONNECTOR-HEADER;BOX,12P,1R,1.25mm,SMD-A
CNP01 3710-001478 CONNECTOR-SOCKET;18P,2R,1MM,SMD-S,SN
CNP02 3708-001474 CONNECTOR-FPC/FC/PIC;22P,0.5mm,SMD-A,SN
CP01 2203-000357 C-CERAMIC,CHIP;0.15nF,5%,50V,NP0,TP,1608
CP02 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP03 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP05 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP06 2203-000799 C-CERAMIC,CHIP;33nF,10%,16V,X7R,TP,1608
CP07 2203-000799 C-CERAMIC,CHIP;33nF,10%,16V,X7R,TP,1608
CP08 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP09 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP10 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP100 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP11 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CP12 2203-000604 C-CERAMIC,CHIP;22nF,10%,25V,X7R,TP,1608
CP13 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP14 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP15 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CP16 2404-000190 C-TA,CHIP;22uF,20%,16V,-,TP,5832,-
CP17 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP18 2203-000815 C-CERAMIC,CHIP;0.033nF,5%,50V,NP0,TP,160
CP19 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP20 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP21 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP22 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP23 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP24 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP25 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CP26 2404-000157 C-TA,CHIP;1uF,20%,35V,-,TP,3216,-
CP27 2404-000212 C-TA,CHIP;3.3uF,20%,25V,-,TP,3528,-
CP28 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP29 2404-000212 C-TA,CHIP;3.3uF,20%,25V,-,TP,3528,-
CP30 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP31 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
CP32 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP33 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP34 2203-001640 C-CERAMIC,CHIP;0.39nF,10%,50V,X7R,TP,160
CP35 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CP36 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP37 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP38 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP39 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP40 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP41 2404-001131 C-TA,CHIP;22UF,10%,10V,GP,TP,3528
CP42 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP43 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP44 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP45 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
CP46 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP47 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP48 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP49 2404-001131 C-TA,CHIP;22UF,10%,10V,GP,TP,3528
CP50 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CP51 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP52 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP53 2203-000041 C-CERAMIC,CHIP;0.01nF,0.25pF,50V,NP0,TP,
CP54 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP55 2203-001640 C-CERAMIC,CHIP;0.39nF,10%,50V,X7R,TP,160
CP56 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP58 2203-000626 C-CERAMIC,CHIP;0.022nF,5%,50V,NP0,TP,160
CP59 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP60 2203-001640 C-CERAMIC,CHIP;0.39nF,10%,50V,X7R,TP,160
CP61 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP62 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP63 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP64 2203-000384 C-CERAMIC,CHIP;0.015nF,5%,50V,NP0,TP,160
CP65 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP66 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP67 2203-000681 C-CERAMIC,CHIP;0.027nF,5%,50V,NP0,TP,160 NTSC
CP67 2203-000426 C-CERAMIC,CHIP;0.018nF,5%,50V,NP0,TP,160 PAL
CP68 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CP69 2203-000998 C-CERAMIC,CHIP;0.047nF,5%,50V,NP0,TP,160
CP70 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CP71 2203-000681 C-CERAMIC,CHIP;0.027nF,5%,50V,NP0,TP,160
CP72 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP73 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP74 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP75 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CP76 2203-001222 C-CERAMIC,CHIP;820pF,10%,50V,X7R,TP,1608
CP77 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP78 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
