Exploded View and Parts List
Loc. No New Part No Description and Specification Remark
149 AC61-32047A PLATE-NUT;SECC,T0.8,-,-,SV-V40 ALL
190 AD97-01483A ASSY-REAR;SCL520,-,- SCL500/L520/VP-L500/L520
AD97-01484A ASSY-REAR;SCL540,-,- SCL530/VP-L530/L530B
AD97-01485A ASSY-REAR;SCL550,-,- SCL550/VP-L550
191 AD64-00243A CASE-REAR;-,ABS94HB BLK,-,-,-,-,-,M2-PJ SCL500/L520/VP-L500/L520
AD64-00243B CASE-REAR;-,ABS94HB BLK,-,-,-,-,-,SCL540 SCL530/VP-L530/L530B
AD64-00243C CASE-REAR;-,ABS94HB BLK,-,-,-,-,-,SCL550 SCL550/VP-L550
192 AD61-00302A BRACKET-REAR;-,SUS304 T0.8,-,-,-,-,M2-PJ ALL
193 AD64-00166A BUTTON--SNAP SHOT;-,ABS 94HB,-,-,-,M1-PJ ALL
195 AD61-00205A HOLDER--BATTERY EJECT;-,-,-,-,ABS94HB,M1 ALL
196 AD61-00209A HOLDER--SNAP SHOT;-,POM,-,NTR,-,M1-PJ ALL
197 AD61-00212A HOLDER--ZOOM;-,POM,-,NTR,-,M1-PJ ALL
199 AD64-00175A KNOB--BATTERY EJECT;-,ABS 94HB,-,-,-,M1- ALL
200 AD64-00181A KNOB--ZOOM;-,ABS 94HB,-,-,-,M1-PJ,- ALL
201 AD64-00176A KNOB-DITECTOR;-,ABS 94HB,-,-,-,M1-PJ,- ALL
202 AD64-00182A LOCKER-BATTERY;-,POM,-,BLK,-,M1-PJ ALL
205 AD61-00218A SPRING--BATTERY EJECT;-,M1-PJ,-,-,0.2,-, ALL
206 AD61-00219A SPRING--BATTERY LOCK;-,M1-PJ,-,-,0.2,-,- ALL
207 AD61-00220A SPRING--SNAP SHOT;-,M1-PJ,-,-,0.2,-,-,-, ALL
208 AD97-01151A ASSY-REAR BOARD;M-P/J,-,- SCL500/L520/L530
VP-L500/L520/L530/L530B
AD97-01356A ASSY-REAR BOARD;M-P/J,-,Hi8 SCL550/VP-L550
221 AD97-01229A ASSY-COVER HOUSING;M1-PJ,-,NORMAL SCL500/L520/L530
VP-L500/L520/L530/L530B
AD97-01230A ASSY-COVER HOUSING;M1-PJ,-,Hi8 SCL550/VP-L550
230 AD97-01231A ASSY-RIGHT;M1-PJ,-,EXP SCL500/L520/L530
VP-L500/L520/L530/L530B
AD97-01994A ASSY-CASE RIGHT;-,M1-PJ,EXP(HOOD SPRAY) SCL550/VP-L550
232 AD97-01655A ASSY-CAP HOOD;M-PRO,-,- SCL500/L520/L530
VP-L500/L520/L530/L530B
AD97-01711A ASSY-CAP HOOD;M1-PJ,ABS94HB GRY,SPRAY SCL550/VP-L550
235 AD61-00214A BRACKET-GRIP BACK;-,-,-,T0.8,-,SUS304,M1 ALL
236 AD61-00077A BRACKET-GRIP FRONT;-,-,SUS T1.2,-,-,-,CS ALL
237 AD64-00165A BUTTON--REC/STOP;-,ABS 94HB,-,-,-,M1-PJ ALL
238 AD63-10219A GRIP-BELT ASSY;-,LEATHER,-,-,BLK,-,SC-L3 ALL
240 AD61-00210A HOLDER--START/STOP;-,-,-,-,POM,M1-PJ ALL
241 AD64-00180A KNOB--START/STOP;-,ABS 94HB,-,-,-,M1-PJ, ALL
242 AD61-60521A SPRING-REC;-,TS,SWPB,0.25,4.3,-,SC-80 ALL
243 AD61-00083A SPRING--S/STOP;-,-,CS99V,-,-,-,- ALL
903 AC60-10020A SCREW-MACHINE;BH,+,M2,X5,FZB,FE,UP,-,- ALL
908 AD60-10001A SCREW-MACHINE;BH,B,1.7*5.5,-,FE,BLACK,-, ALL
909 AD60-00003A SCREW-TAPTITE;-,+,-,H8.5,2X6,- ALL
