Samsung SCL520 - Page 104

Samsung Electronics 6-19
Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
Q601 0504-001040 TR-DIGITAL;KRC403,NPN,100MW,22K/22K,SOT-
Q701 0501-000546 TR-SMALL SIGNAL;KTA1298,PNP,200mW,SOT-23
Q702 0504-001038 TR-DIGITAL;KRC402,NPN,100MW,10K/10K,SOT-
Q703 0501-002312 TR-SMALL SIGNAL;HN2C01FU,NPN,200mW,UMD6,
Q761 0504-001036 TR-DIGITAL;KRA304,PNP,100mW,47K/47Kohm,S
Q762 0501-000218 TR-SMALL SIGNAL;2SC4081,NPN,200mW,UMT,TP
Q901 0501-000681 TR-SMALL SIGNAL;FP101,PNP,1.3W,PCP4,TP,1
Q902 0501-000546 TR-SMALL SIGNAL;KTA1298,PNP,200mW,SOT-23
Q903 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT-
Q906 0501-000681 TR-SMALL SIGNAL;FP101,PNP,1.3W,PCP4,TP,1
Q907 0501-000681 TR-SMALL SIGNAL;FP101,PNP,1.3W,PCP4,TP,1
Q908 0501-000172 TR-SMALL SIGNAL;2SB1121,PNP,500mW,PCP,TP
Q909 0501-000681 TR-SMALL SIGNAL;FP101,PNP,1.3W,PCP4,TP,1
QP01 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT-
QP02 0501-000218 TR-SMALL SIGNAL;2SC4081,NPN,200mW,UMT,TP
QP03 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT-
QP04 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT-
QP05 0504-001040 TR-DIGITAL;KRC403,NPN,100MW,22K/22K,SOT-
QP06 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT-
QP07 0501-000596 TR-SMALL SIGNAL;2SB970R,PNP,200MW,SOT-23
QP08 0501-002171 TR-SMALL SIGNAL;KTA2014,PNP,100mW,SOT-32
QP09 0501-000218 TR-SMALL SIGNAL;2SC4081,NPN,200mW,UMT,TP
QP10 0501-002171 TR-SMALL SIGNAL;KTA2014,PNP,100mW,SOT-32
QP11 0501-002171 TR-SMALL SIGNAL;KTA2014,PNP,100mW,SOT-32
QP12 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT-
R002 2007-000106 R-CHIP;220Kohm,5%,1/16W,DA,TP,1608
R003 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R004 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R005 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R006 2007-000125 R-CHIP;3.9Kohm,5%,1/16W,DA,TP,1608
R007 2007-000082 R-CHIP;3.3Kohm,5%,1/16W,DA,TP,1608
R008 2007-000458 R-CHIP;18Kohm,5%,1/16W,DA,TP,1608
R009 2007-000458 R-CHIP;18Kohm,5%,1/16W,DA,TP,1608
R010 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608
R013 2007-000118 R-CHIP;390ohm,5%,1/16W,DA,TP,1608
R014 2007-000118 R-CHIP;390ohm,5%,1/16W,DA,TP,1608
R015 2007-000130 R-CHIP;39Kohm,5%,1/16W,DA,TP,1608
R016 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608
R017 2007-000082 R-CHIP;3.3Kohm,5%,1/16W,DA,TP,1608
R018 2007-000082 R-CHIP;3.3Kohm,5%,1/16W,DA,TP,1608
R019 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R020 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R021 2007-000134 R-CHIP;33Kohm,5%,1/16W,DA,TP,1608
R022 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R023 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
R024 2007-000122 R-CHIP;1.2Kohm,5%,1/16W,DA,TP,1608 NTSC
R024 2007-000120 R-CHIP;680ohm,5%,1/16W,DA,TP,1608 PAL
R025 2007-000643 R-CHIP;270ohm,5%,1/16W,DA,TP,1608
R026 2007-000071 R-CHIP;22ohm,5%,1/16W,DA,TP,1608
R031 2007-000458 R-CHIP;18Kohm,5%,1/16W,DA,TP,1608
R032 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608
R033 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608
R034 2007-000134 R-CHIP;33Kohm,5%,1/16W,DA,TP,1608
R035 2007-000122 R-CHIP;1.2Kohm,5%,1/16W,DA,TP,1608
R036 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R037 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R038 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
R039 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608
R040 2007-000134 R-CHIP;33Kohm,5%,1/16W,DA,TP,1608
R041 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
R042 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608
R043 2007-000121 R-CHIP;820ohm,5%,1/16W,DA,TP,1608
R046 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R051 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R071 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R072 2007-000082 R-CHIP;3.3Kohm,5%,1/16W,DA,TP,1608
R073 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
R101 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R102 2007-000120 R-CHIP;680ohm,5%,1/16W,DA,TP,1608
R103 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608
R104 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R105 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608
R106 2007-000118 R-CHIP;390ohm,5%,1/16W,DA,TP,1608
R107 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R108 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R109 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
R110 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
R111 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R112 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
R113 2007-000121 R-CHIP;820ohm,5%,1/16W,DA,TP,1608
R114 2007-000087 R-CHIP;6.8Kohm,5%,1/16W,DA,TP,1608
R115 2007-000087 R-CHIP;6.8Kohm,5%,1/16W,DA,TP,1608
R116 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R117 2007-000134 R-CHIP;33Kohm,5%,1/16W,DA,TP,1608
R118 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R119 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R120 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R121 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R122 2007-000121 R-CHIP;820ohm,5%,1/16W,DA,TP,1608
R123 2007-000643 R-CHIP;270ohm,5%,1/16W,DA,TP,1608
