NO-OSD-DISPLAY DISTANCE
ADDR MODEL/DATA CONTENT
NTSC PAL
NOR HI8 NOR HI8 OPTION D6 D5 D4 D3 D2 D1 D0
Samsung Electronics4-8
Alignment and Adjustment
072 80 8A 80 8A OUTDOOR DECISION BY HALL VALUE
073 70 60 70 60 AWB;AWB TRACKING HALL2( WB TRACKING AVAILABLE BETWEEN #072~#072-#073)
074 04 07 06 04 W/B TRACKING AREA SELECT
075 0C 0C 0C 0C WB STABLE MODE THRESHOLD
076 10 10 10 10 |---- AWB CUTTING THRESHOLD1 Y LEVEL INTERVAL ----|
077 10 10 10 10 |---- AWB CUTTING THRESHOLD2 TOP LEVEL INTERVAL ----|
078 40 40 40 40 |---- AWB CUTTING THRESHOLD3 R CONTROL LOW MARGIN ----|
079 40 40 40 40 |---- AWB CUTTING THRESHOLD4 DATA CUT LOW ----|
07A 00 00 00 00 |---- AWB CUTTING THRESHOLD1 DATA CUT HIGH ----|
07B 60 6A 60 6A * AWB HALL STOP AT SPOLTLIGHT MODE
07C 80 8A 80 8A * AWB HALL AT EIS MODE
07D F0 F0 F0 F0 * AWB HALL STOP AT SPORTS/PORTRAIT/SAND&SNOW/HSS MODE
07E F4 F4 F4 F4 @D/ZOOM RATIO MAX DATA( 80:2 TIMES, CO:4 TIMES, F4:20 TIMES)
07F 17 17 1B 1B ZOOM MAX SPEED ;22X LENS PAL:1BH ,NTSC:17H )
080 07 07 09 09 REMCON ZOOM SPEED X22 PAL:09 NTSC:07 )
081 0A 00 09 F8 @CCD H-PIXEL NUMBER -LOW BYTE
082 02 03 02 02 @CCD H-PIXEL NUMBER -HIGH BYTE
083 F7 F7 23 23 @CCD V LINE NUMBER -LOW BYTE 1/2
084 00 00 01 01 @CCD V LINE NUMBER -HIGH BYTE 1/2
085 09 09 0C 0C @V SKIP LINE NUMBER
086 00 11 00 00 DIS;VMX,VMY MAX-#086 (11:NTSC HI-8, 00:ETC)
087 00 00 00 00 @CCD V LINE NUMBER HIGH BYTE
088 1D 1D 1D 1D @DSP IC ADDR #39H ;MOSAIC SIZE :VTR
089 98 98 98 98 @DSP IC ADDR #41H ;ART DSE LEVEL :VTR
08A B8 B8 B8 B8 @DSP IC ADDR #1CH ;NEGA MODE WHITE CLIP LEVEL :VTR
08B 75 75 75 75 @SEPIA CDS-R
08C 3A 3A 3A 3A @SEPIA CDS-G
08D 10 10 11 11 @CINEMA F-ZONE LIMIT UP
08E 68 68 7D 7D @CINEMA F-ZONE LIMIT UP
08F 01 01 01 01 @DSP IC ADDR #00H ;EMODE,CINEMA :VTR
090 88 88 88 88 @DSP IC ADDR #07H ;ADCLDEL. DSCKDEL,FWCKDLY :VTR
091 2E 2E 1B 1B @DSP IC ADDR #08H ;HCNTSET :VTR
092 00 00 00 00 @DSP IC ADDR #0AH ;DCKSEL,VCNTSET :VTR
093 4A 4C 4B 4A @DSP IC ADDR #10H ;C-SYNC :VTR
094 CE CE DB D8 @DSP IC ADDR #14H ;EUSC(B-Y) BURST :VTR
095 00 00 24 28 @DSP IC ADDR #15H ;EVSC(R-Y)BURST :VTR
096 77 77 77 77 @DSP IC ADDR #20H ;YVBTH,YVBKG,YHBKTH,YHBKG :VTR
097 B8 B8 B8 B8 @DSP IC ADDR #28H ;VCR_ADJ,WHITE LEVEL :VTR
098 7F 7F 7F 7F @DSP IC ADDR #47H ;CRYGP :VTR
099 7F 7F 7F 7F @DSP IC ADDR #48H ;CRYGN :VTR
09A 7F 7F 7F 7F @DSP IC ADDR #4BH ;CRYGP :VTR
