Samsung Electronics 5-15
Exploded View and Parts List
Loc. No New Part No Description and Specification Remark
004 AC60-10017A SCREW-MACHINE;BH,+,M1.7,X3.5,FEFZY,SWCH1
005 AC60-12112A SCREW-BH;-,BH,+,M1.4,L2,-
020 AC60-30017A WASHER-SLIT;ID 1,OD 2.6,T 0.4,POLYSLIDER
501 AD31-12010A MOTOR-CAPSTAN;DE-6B SHS,-,-
AD31-12001Q MOTOR-CAPSTAN;DMCCHL06A(DE-6),-,-
502 AC66-22123A GEAR-CAPSTAN(ASS’Y);-,-,-,-,-,DE-6
503 AC66-22124A GEAR-PULLEY(ASS’Y);-,-,-,-,-,DE-6
504 AC66-62001A BELT-TIMMING;POLYURETHAN,L137 T0.4,-,-,-
505 AC66-32197A LEVER-CAM;SUS430-CP,T0.6,-,-,DE-6,-
506 AC66-42005A ROLLER-CAM MAIN;SUS303,-,-,PI3.5X1.1
507 AC66-22092A GEAR-CAM MAIN;SUS304-CSP,M0.5,Z64,-,-,-
508 AC66-82055A SLIDER-MAIN(ASS’Y);-,-,-,-,DE-6
509 AC66-32198A LEVER-EJECT;DURANEX #3300,-,-,-,DE-6,-
510 AC34-22001C SWITCH-MODE ASS’Y;HMW0484-01WA,DE-6,-,-,-
511 AC66-22126A GEAR-LOADING;DURACON(99-44),M0.4,Z37 WO,
512 AC31-12001P MOTOR-LOADING ASS’Y;DE-6,-,-
