Samsung Electronics 6-1
6. Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
C155 2203-000604 C-CERAMIC,CHIP;22nF,10%,25V,X7R,TP,1608
C156 2203-000332 C-CERAMIC,CHIP;0.012nF,5%,50V,NP0,TP,160 NTSC
C156 2203-000384 C-CERAMIC,CHIP;0.015nF,5%,50V,NP0,TP,160 PAL
C157 2203-000815 C-CERAMIC,CHIP;0.033nF,5%,50V,NP0,TP,160
C181 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C182 2203-000236 C-CERAMIC,CHIP;0.1nF,5%,50V,NP0,TP,1608
C183 2203-001408 C-CERAMIC,CHIP;0.27nF,5%,50V,NP0,TP,1608
C184 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C201 2203-000332 C-CERAMIC,CHIP;0.012nF,5%,50V,NP0,TP,160 NTSC
C201 2203-000384 C-CERAMIC,CHIP;0.015nF,5%,50V,NP0,TP,160 PAL
C202 2404-001131 C-TA,CHIP;22UF,10%,10V,GP,TP,3528
C203 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C206 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C207 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C208 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
C209 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C210 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
C211 2203-000236 C-CERAMIC,CHIP;0.1nF,5%,50V,NP0,TP,1608
C212 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C213 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C214 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C215 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C216 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C218 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608,
C219 2404-000167 C-TA,CHIP;2.2uF,20%,16V,-,TP,3216,-
C220 2404-000151 C-TA,CHIP;1uF,20%,16V,-,TP,3216,-
C221 2404-000218 C-TA,CHIP;330nF,20%,35V,-,TP,3216,-
C222 2404-000167 C-TA,CHIP;2.2uF,20%,16V,-,TP,3216,-
C223 2203-001656 C-CERAMIC,CHIP;0.47nF,5%,50V,NP0,TP,1608 NTSC
C223 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 PAL
C224 2203-001607 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0,TP,1608 NTSC
C224 2203-000715 C-CERAMIC,CHIP;3.3nF,10%,50V,X7R,TP,1608 PAL
C225 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C226 2203-001640 C-CERAMIC,CHIP;0.39nF,10%,50V,X7R,TP,160
C227 2203-001640 C-CERAMIC,CHIP;0.39nF,10%,50V,X7R,TP,160
C228 2203-001607 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0,TP,1608
C229 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
C231 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C232 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C233 2203-000357 C-CERAMIC,CHIP;0.15nF,5%,50V,NP0,TP,1608 NTSC
C233 2203-001697 C-CERAMIC,CHIP;0.082nF,5%,50V,NP0,TP,160 PAL
C234 2203-000922 C-CERAMIC,CHIP;470nF,+80-20%,25V,Y5V,TP,
ASSY-MAIN BOARD (NORMAL)
C101 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C102 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C103 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C104 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C105 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C106 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C107 2203-000888 C-CERAMIC,CHIP;4.7nF,10%,50V,X7R,TP,1608
C108 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
C109 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C110 2404-001131 C-TA,CHIP;22UF,10%,10V,GP,TP,3528
C111 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C112 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C113 2404-001039 C-TA,CHIP;47uF,20%,6.3V,GP,TP,3528,-
C114 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C115 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C116 2203-000604 C-CERAMIC,CHIP;22nF,10%,25V,X7R,TP,1608
C117 2203-000604 C-CERAMIC,CHIP;22nF,10%,25V,X7R,TP,1608
C118 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C119 2404-001039 C-TA,CHIP;47uF,20%,6.3V,GP,TP,3528,-
C120 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C121 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C130 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C131 2203-001686 C-CERAMIC,CHIP;0.075nF,5%,50V,NP0,TP,160
C132 2203-000357 C-CERAMIC,CHIP;0.15nF,5%,50V,NP0,TP,1608
C133 2203-000236 C-CERAMIC,CHIP;0.1nF,5%,50V,NP0,TP,1608
C134 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C140 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
C141 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C142 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C143 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C144 2203-001408 C-CERAMIC,CHIP;0.27nF,5%,50V,NP0,TP,1608
C145 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C146 2203-001113 C-CERAMIC,CHIP;0.062nF,5%,50V,NP0,TP,160
C147 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608
C148 2203-001408 C-CERAMIC,CHIP;0.27nF,5%,50V,NP0,TP,1608
C149 2203-000426 C-CERAMIC,CHIP;0.018nF,5%,50V,NP0,TP,160
C150 2203-000604 C-CERAMIC,CHIP;22nF,10%,25V,X7R,TP,1608
C151 2203-000604 C-CERAMIC,CHIP;22nF,10%,25V,X7R,TP,1608
C152 2203-000604 C-CERAMIC,CHIP;22nF,10%,25V,X7R,TP,1608
C153 2203-000604 C-CERAMIC,CHIP;22nF,10%,25V,X7R,TP,1608
C154 2203-000332 C-CERAMIC,CHIP;0.012nF,5%,50V,NP0,TP,160
