Samsung SCL520 - Page 92

Samsung Electronics 6-7
Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
Q908 0501-000172 TR-SMALL SIGNAL;2SB1121,PNP,500mW,PCP,TP
Q909 0501-000681 TR-SMALL SIGNAL;FP101,PNP,1.3W,PCP4,TP,1
QP01 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT-
QP02 0501-002128 TR-SMALL SIGNAL;KTC4075,NPN,100mW,USM,TP
QP03 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT-
QP04 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT-
QP05 0504-001040 TR-DIGITAL;KRC403,NPN,100MW,22K/22K,SOT-
QP06 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT-
QP07 0501-000596 TR-SMALL SIGNAL;2SB970R,PNP,200MW,SOT-23
QP08 0501-002171 TR-SMALL SIGNAL;KTA2014,PNP,100mW,SOT-32
QP09 0501-002128 TR-SMALL SIGNAL;KTC4075,NPN,100mW,USM,TP
QP10 0501-002171 TR-SMALL SIGNAL;KTA2014,PNP,100mW,SOT-32
QP11 0501-002171 TR-SMALL SIGNAL;KTA2014,PNP,100mW,SOT-32
QP12 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT-
R101 2007-000123 R-CHIP;1.5Kohm,5%,1/16W,DA,TP,1608
R102 2007-000082 R-CHIP;3.3Kohm,5%,1/16W,DA,TP,1608
R103 2007-000081 R-CHIP;2.7Kohm,5%,1/16W,DA,TP,1608
R104 2007-000082 R-CHIP;3.3Kohm,5%,1/16W,DA,TP,1608
R105 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
R106 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
R107 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
R108 2007-000100 R-CHIP;68Kohm,5%,1/16W,DA,TP,1608
R111 2007-000123 R-CHIP;1.5Kohm,5%,1/16W,DA,TP,1608
R112 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
R113 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608
R114 2007-000118 R-CHIP;390ohm,5%,1/16W,DA,TP,1608
R115 2007-000118 R-CHIP;390ohm,5%,1/16W,DA,TP,1608
R116 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608
R117 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
R118 2007-000123 R-CHIP;1.5Kohm,5%,1/16W,DA,TP,1608
R130 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R131 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R132 2007-000134 R-CHIP;33Kohm,5%,1/16W,DA,TP,1608
R133 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R134 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
R135 2007-000643 R-CHIP;270ohm,5%,1/16W,DA,TP,1608
R136 2007-000082 R-CHIP;3.3Kohm,5%,1/16W,DA,TP,1608
R137 2007-000071 R-CHIP;22ohm,5%,1/16W,DA,TP,1608
R140 2007-000458 R-CHIP;18Kohm,5%,1/16W,DA,TP,1608
R141 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608
R142 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608
R143 2007-000134 R-CHIP;33Kohm,5%,1/16W,DA,TP,1608
R144 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
R145 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R146 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R147 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R148 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
R149 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608
R150 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
R151 2007-000134 R-CHIP;33Kohm,5%,1/16W,DA,TP,1608
R152 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608
R153 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R154 2007-000121 R-CHIP;820ohm,5%,1/16W,DA,TP,1608
R155 2007-000121 R-CHIP;820ohm,5%,1/16W,DA,TP,1608
R156 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R157 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
R158 2007-000123 R-CHIP;1.5Kohm,5%,1/16W,DA,TP,1608
R159 2007-000122 R-CHIP;1.2Kohm,5%,1/16W,DA,TP,1608 NTSC
R159 2007-001157 R-CHIP;750ohm,5%,1/16W,DA,TP,160 PAL
R160 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R161 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608
R162 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608 NTSC
R162 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608 PAL
R163 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608
R164 2007-000079 R-CHIP;1.8Kohm,5%,1/16W,DA,TP,1608
R165 2007-000123 R-CHIP;1.5Kohm,5%,1/16W,DA,TP,1608
R166 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R167 2007-000458 R-CHIP;18Kohm,5%,1/16W,DA,TP,1608
R168 2007-000458 R-CHIP;18Kohm,5%,1/16W,DA,TP,1608
R169 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R170 2007-000123 R-CHIP;1.5Kohm,5%,1/16W,DA,TP,1608
R171 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
R180 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R181 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R182 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
R183 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608
R184 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R185 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R186 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
R201 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R205 2007-000583 R-CHIP;22Kohm,1%,1/16W,DA,TP,1608
R206 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608 NTSC
R206 2007-000120 R-CHIP;680ohm,5%,1/16W,DA,TP,1608 PAL
R207 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R210 2007-000081 R-CHIP;2.7Kohm,5%,1/16W,DA,TP,1608
R211 2007-000082 R-CHIP;3.3Kohm,5%,1/16W,DA,TP,1608 NTSC
R211 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608 PAL
R212 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R213 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R214 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
