Samsung Electronics6-12
Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
X601 2801-003239 CRYSTAL-SMD;11.71875MHz,50ppm,28-ABL,13p PAL
XP01 2801-003919 CRYSTAL-SMD;28.636MHz,40ppm,28-ABL,7pF,6 NTSC
XP01 2801-003918 CRYSTAL-SMD;28.375MHz,40ppm,28-ABL,7pF,6 PAL
XP02 2801-000258 CRYSTAL-UNIT;32.768KHz,20ppm,28-AAW,12
XP03 2801-003242 CRYSTAL-SMD;11.895104MHz,50ppm,28-ABL,13
ASSY-MAIN BOARD (HI8)
C001 2203-000332 C-CERAMIC,CHIP;0.012nF,5%,50V,NP0,TP,160
C002 2203-000888 C-CERAMIC,CHIP;4.7nF,10%,50V,X7R,TP,1608
C003 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C004 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C005 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C006 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
C007 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C008 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C010 2203-000783 C-CERAMIC,CHIP;0.33nF,5%,50V,NP0,TP,1608
C011 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
C012 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C014 2404-001039 C-TA,CHIP;47uF,20%,6.3V,GP,TP,3528,-
C015 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C017 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C018 2203-000626 C-CERAMIC,CHIP;0.022nF,5%,50V,NP0,TP,160
C019 2203-000604 C-CERAMIC,CHIP;22nF,10%,25V,X7R,TP,1608
C020 2203-000604 C-CERAMIC,CHIP;22nF,10%,25V,X7R,TP,1608
C021 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C022 2203-000626 C-CERAMIC,CHIP;0.022nF,5%,50V,NP0,TP,160
C023 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C024 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C025 2404-001039 C-TA,CHIP;47uF,20%,6.3V,GP,TP,3528,-
C026 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C027 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C028 2404-001131 C-TA,CHIP;22UF,10%,10V,GP,TP,3528
C029 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C030 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C031 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
C032 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C033 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C034 2203-001417 C-CERAMIC,CHIP;0.036nF,5%,50V,NP0,TP,160
C035 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608
C037 2203-001408 C-CERAMIC,CHIP;0.27nF,5%,50V,NP0,TP,1608
C038 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C052 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C053 2203-001686 C-CERAMIC,CHIP;0.075nF,5%,50V,NP0,TP,160
C054 2203-000357 C-CERAMIC,CHIP;0.15nF,5%,50V,NP0,TP,1608
C055 2203-000236 C-CERAMIC,CHIP;0.1nF,5%,50V,NP0,TP,1608
C056 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
RP62 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP63 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP64 2007-000109 R-CHIP;1Mohm,5%,1/16W,DA,TP,1608
RP65 2007-000079 R-CHIP;1.8Kohm,5%,1/16W,DA,TP,1608
RP66 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP68 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP69 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP70 2007-000402 R-CHIP;150ohm,5%,1/16W,DA,TP,1608
RP71 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP72 2007-000123 R-CHIP;1.5Kohm,5%,1/16W,DA,TP,1608
RP73 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP74 2007-000122 R-CHIP;1.2Kohm,5%,1/16W,DA,TP,1608
RP75 2007-000052 R-CHIP;10Kohm,1%,1/16W,DA,TP,1608
RP76 2007-000402 R-CHIP;150ohm,5%,1/16W,DA,TP,1608
RP77 2007-000583 R-CHIP;22Kohm,1%,1/16W,DA,TP,1608
RP78 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
RP79 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP80 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP81 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
RP82 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RP83 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
RP84 2007-000402 R-CHIP;150ohm,5%,1/16W,DA,TP,1608
RP85 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP86 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RP87 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RP88 2007-000122 R-CHIP;1.2Kohm,5%,1/16W,DA,TP,1608
RP89 2007-000052 R-CHIP;10Kohm,1%,1/16W,DA,TP,1608
RP90 2007-000583 R-CHIP;22Kohm,1%,1/16W,DA,TP,1608
RP91 2007-000402 R-CHIP;150ohm,5%,1/16W,DA,TP,1608
RP92 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP93 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP94 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
RP95 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RP96 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RP97 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP98 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608
RP99 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608
RW01 2007-000863 R-CHIP;4.3OHM,5%,1/10W,DA,TP,2012
SW601 3404-001034 SWITCH-TACT;12V,50mA,160gf,4x7.4x1.8mm,S
SW603 3404-001034 SWITCH-TACT;12V,50mA,160gf,4x7.4x1.8mm,S
SW604 3404-001034 SWITCH-TACT;12V,50mA,160gf,4x7.4x1.8mm,S
SW605 3404-001034 SWITCH-TACT;12V,50mA,160gf,4x7.4x1.8mm,S
SW606 3404-001034 SWITCH-TACT;12V,50mA,160gf,4x7.4x1.8mm,S
T901 AD26-00017A TRANS;-,42uH,8P,15V,460KHz,FERRITE,M
X601 2801-003242 CRYSTAL-SMD;11.895104MHz,50ppm,28-ABL,13 NTSC
