5-3

Exploded Views and Parts List

NO DESCRIPTION SEC CODE Q’TY SA REMARK

1 UNIT-SCAN ASSY TBD 1

1-1 ELA HOU-ADF JC96-02654A 1

1-2 ELA HOU-PLATEN JC96-02657A 1

1-3 ELA HOU-OPE JC96-02658A 1

1-4 CBF-ROCKY_ADF_HARNESS ADF_HARNESS 1

1-5 PMO-COVER WINDOW COVER WINDOW 1

1-6 ROCKY_CONN_PBA CONN_PBA 1

2 ELA HOU-FRAME(220V) JC96-02710A 1

3 ELA HOU-RX DRIVE 1400 NEW-DRIVE ASSY 1

4 UNIT-LSU N202 1

5 CBF HARNESS-LSU 1400 NH3 1

7 SHIELD TBC 1

7-1 SMPS-110V SMPS 1

7-2 CBF HARNESS-MAIN_SMPS K1 1

7-3 BRACKET-P-INLET, ROCKY JC61-00693A 1

7-4 SHIELD-ENGINE, ROCKY JC63-00144A 1

8 PBA MAIN-MAIN JC92-01431A 1

9 ELA UNIT-COVER MIDDLE JC97-01723A 1

9-9 COVER-M-REAR UPPER JC63-00143A 1

9-1 COVER-M-MIDDLE JC63-00141A 1

9-2 PMO-STACKER_RX JC72-00973A 1

9-3 RING-CS 6044-000001 2

9-4 GEAR-IDLE 23 JC66-00396A 1

9-5 PMO-GEAR_EXIT_DRV16 JC72-00143A 1

9-6 GEAR-EXIT F/DOWN JC66-00038A 1

9-7 MEC-BEARING,EXIT JC75-10529A 2

9-8 ROLLER-EXIT_F/DOWN JC66-00378A 1

9-9 RMO-RUBBER EXIT JC73-40915A 1

9-10 TBD

9-11 SPRING-EXIT_F/DOWN JC33-00010A 4

9-12 HOLDER-EXIT_F/DOWN JC61-00582A 4

9-13 PMO-ROLLER_EXIT,MAIN JC72-41081A 4

9-14 PMO-ROLLER_EXIT,FR JC72-41082A 4

< Main Assembly Parts List >

SA. : Service Available

O: Service available X: Service not available
