Page #85 background imageLoading...
Page #85 background image
5-4
Exploded Views and Parts List
10 MEA ETC-COVER FRONT
TBD
1
10-1 ADJUST-MANUAL R JC70-00303A 1
10-2 ADJUST RACK-MANUAL JC70-00304A 1
10-3 COVER-FRONT JC63-00103A 1
10-4 ADJUST-MANUAL L JC70-00302A 1
10-5 GEAR-RACK_PINION JC66-00387A 1
11 MEA ETC-CASSETTE 1400 TBD 1
12 ELA HOU COVER SIDE L JC96-02709A 1
12-1 COVER-M-SIDE L JC63-00137A 1
12-2 SPEAKER 3001-001293 1
13 COVER-M-SIDE R JC63-00138A 1
14 MEA UNIT- COVER REAR JC97-01724A 1
14-1 COVER-M-REAR JC63-00140A 1
14-2 COVER-M-FACE UP JC63-00142A 1
15 FAN-DC TBD 1
TBD IPR-PLATE_CHANNEL JC61-00606A 1
16 CBF HARNESS-MOTOR NH4 1
17 ROLLER-TRANSFER ROLLER JC66-00528A 1
18 PMO-GEAR TRANSFER JC66-00395A 1
TBD ROCKY_SCAN_FFC SCAN_FFC 1
TBD CABLE-FLAT 3809-001161 1
TBD SUPPORTER 6103-001048 1
20 ELA TONER UNIT,ROCKY JC96-02707A 1
19 ROCKY_LIU_PBA LIU_PBA 1
< Main Unit Parts List >
SA. : Service Available
NO DESCRIPTION SEC CODE QTY SA REMARK
O: Service available X: Service not available
