Samsung SCX-4216F Series User Manual

5-6
Exploded Views and Parts List
< ADF Unit Parts List >
SA. : Service Available
NO DESCRIPTION SEC CODE Q’TY SA REMARK
0 ELA HOU-ADF JC96-02654A 1
1 MEA UNIT-ADF UPPER ASS`Y TBD 1
1-1 COVER-M-ADF UPPER JC63-00145A 1
1-2 ROLLER-M-ADF IDLE JC66-00461A 1
1-3 HOLDER-ADF ASSY JC97-01709A 1
1-3-1 RMO-ADF RUBBER JB73-00052A 1
1-3-2 HOLDER-M-ADF JC61-00694A 1
1-3-3 SPRING ETC-PAD JC61-00387A 1
1-3-4 SHEET-ADF SHEET-ADF 1
2 ELA UNIT-ADF LOWER ASS`Y JC96-02668A 1
2-1 COVER-M-ADF LOWER JC63-00148A 1
2-2 CBF D SUB CABLE-ADF_MAIN CABLE JC39-00190A 1
2-3 GROUND-P-ADF JC63-00149A 1
2-4 SHAFT-M-FEED GEAR 38 JC66-00460A 1
2-5 ROLLER-DRIVE JC66-00560A 1
2-6 PMO-ACTUATOR DOC SENSOR JC72-01009A 1
2-7 PMO-ACTUATOR REGI SENSOR JC72-01010A 1
2-8 PMO-ACTUATOR SCAN SENSOR JC72-01011A 1
2-9 SPRING ETC-TORSION DOC (CC2-F) JB61-00076A 3
2-10 IPR-GROUND_ROLLER JC70-10467A 1
2-11 CBF HARNESS-DRIVER GND JB39-00065A 1
2-12 ROLLER-EXIT JC66-00559A 1
2-13 MEC-BRUSH ANTISTATIC JC75-00161A 1
2-14 SHEET-WHITE BAR JC63-00154A 1
2-15 PMO-BUSH JB72-00819A 4
2-16 SHAFT-M-EXIT GEAR 27 JC66-00459A 1
3 ELA HOU-ADF MOTOR JC96-02652A 1
3-1 BRACKET-M-GEAR, ADF JC61-00692A 1
3-2 MOTOR BLOWER-ADF JC31-00023A 1
3-3 GEAR-CLUTCH 29 JB66-00101A 1
3-4 PMO-WHITE CLUTCH SUB 29 JB72-00844A 1
3-5 GEAR-CLUTCH 39 JC66-00322A 1
3-6 RING-C 6044-000159 1
3-7 GEAR-IDLE 35 ADF JC66-00458A 3
3-8 GEAR-40/21 ADF JC66-00456A 3
3-9 GEAR-SWING 31/20 ADF JC66-00457A 1
3-10 LINK-M-SWING ADF JC66-00454A 1
3-11 GEAR-58/25 ADF JC66-00455A 1
3-12 IMPELLER-ADF JC66-00556A 1
O: Service available X: Service not available

Samsung SCX-4216F Series Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Fax Modem Speed	33.6 Kbps
Paper Input Capacity	250 sheets
Memory	8 MB
Print Speed	16 ppm
Copy Speed	16 cpm
Scan Resolution	4800 x 4800 dpi (enhanced)
Connectivity	USB
