Exploded Views and Parts List
< ADF Unit Parts List >
SA. : Service Available
NO DESCRIPTION SEC CODE Q’TY SA REMARK
3-13 GEAR-REMOVE ADF JC66-00557A 1
3-14 WASHER-PLAIN 6031-000023 1
3-15 SPRING ETC CLUTCH JB61-70922A 1
4 MEA-COVER PLATEN(4IN1) JC97-01708A 1
5 MEA-COVER OPEN JC97-01706A 1
5-1 COVER-M-OPEN JC63-00147A 1
5-2 PMO-GUIDE PAPER JB72-00843A 2
5-3 TBD 2
5 ROCKY_ADF_PBA ADF_PBA 1
6 MEA UNIT-PICKUP ASS`Y TBD 1
6-1 PMO-BUSHING WHITE JF72-41306A 1
6-2 GEAR-ADF 38 JB66-00103A 1
6-3 RING-C 6044-000159 1
O: Service available X: Service not available
To Next Page
