12.2.2 Service Parts
ELA HOU-SCANNER ASS’Y ELA=Electrical Assembly, HOU =Housing
MEA UNIT-COVER PA EXIT ASS’Y MEA= Mechanical Assembly, PA=Paper
PMO-TRAY EXTENTION MP NE PMO= Processing Mold
MP=Multi-Purpose(Bypass) tray
NE=for NEC (common as Samsung Halk printer)
MEC-CASSETTE ASS’Y(LETTER) MEC = Mechanic Combined unit
COVER-M-FRONT M=Mold
MPR-NAME/PLATE MPR= Machinery Press,
UNIT-LSU LSU =Laser Scanning Unit
SMPS-SMPS(V1)+HVPS SMPS =Switching Mode Power Supply
HVPS =High Voltage Power Supply
ELA-OPC UNIT SET OPC=Organic Photo-Conductive
ELA HOU-MP ASS’Y MP =Multi-Purpose (Bypass) tray
PBA MAIN-MAIN PBA =Printed circuit Board Assembly
PMO-CONNECT PAPER MFP MFP =Multi-Functional Peripheral
FAN-DC DC =Direct Current
CBF POWER STITCH GRAY CBF= Cable Form
MEA UNIT GUIDE CST PA ASS’Y CST=Cassette(Paper tray), PA=Paper
PBA LIU PBA =Printed circuit Board Assembly
LIU =Line Interface Unit for FAX
SHIELD-P_MAIN LOWER P=Press
CBF HARNESS-LIU GND LIU =Line Interface Unit for FAX
GND= Ground
PMO-COVER FEED AY AY=Assembly
PMO-COVER BRKT MOTER BRKT=Bracket
CBF HARNESS-LSU LSU =Laser Scanning Unit
IPR-SHIELD SMPS UPPERI IPR=Iron Press
PMO-BUSHING P/U.MP P/U=Pickup
MP=Multi-Purpose (Bypass) Tray
PMO-HOLDER GEAR TRr TR= Transfer Roller
SPRING ETC-TR_L TR_L=Transfer Roller - Left
