Reference Information
Samsung Electronics
Service Manual
12-5
SPRING CS RE CS=Compress
RE=Rear
SPRING CS FR CS=Compress
FR=Front
PMO-BUSHING FINGER, F F=Front
ICT-SHAFT-EXIT LOWER ID ID=Idler
SPRING-EXIT ROLL FD FD=Face Down
PMO-BUSHING_P/U,MP P/U=Pickup
MP =Multi-Purpose (Bypass) tray
PMO-HOLDER CAM MPF MPF=Multi-Purpose Feeder(=MP)
PMO-GEAR P/U MPF P/U=Pickup
MFP =Multi-Functional Peripheral
RPR-RUBBER PICK UP,MP RPR=Rubber Press
PBA SUB-MP SEN PBA SUB-MP-SEN =>Sub Printed circuit Board
Assembly for the MP-SEN(= Multi-Purpose (Bypass)
tray-Sensor)
A/S MATERAL-PICKUP,MP
FOOT-ML80
HOLDER CATCH CST MC2 MC2=>McKInley2 (Samsung Project code name)
IPR-GROUND PLATE A(OPC) OPC=Organic Photo-Conductive
ELA M/M-AUD SPEAKER ELA M/M => Electrical Assembly M/M
AUD=Audio
CBF HARNESS-OPC GND OPC GNG=Organic Photo-Conductive-Ground
IPR-GROUND PLATE SCF SCF=Second Cassette Feeder(Tray2)
PBA SUB-PTL PBA SUB-PTL=>Sub Printed circuit Board Assembly
for the PTL(= Pre Transfer Lamp)
PBA SUB-FEED+P.EMP SEN. PBA SUB-FEED=>Sub Printed circuit Board
Assembly for the feeder
EMP SEN=Empty Sensor
MOTOR STEP-MCK2(MAIN)
GEAR-EXIT/U EXIT/U=EXIT/Upper
GEAR-RDCN FEED INNER RDCN=Reduction
CBF-HARNESS-MAIN-THV WIRE THV =Transfer High Voltage
CBF-HARNESS-MAIN-MHV WIRE MHV= High Voltage(Charge Voltage)
ACRONYM EXPLANATION
