Samsung SCX 6322DN - B/W Laser - All-in-One Service Manual

5. Disassembly and Reassembly
5.1 General Precautions on Disassembly 5-1
5.2 Rear Cover
5-1
5.3 Scanner Ass'y
5-2
5.4 DADF Ass’y
5-7
5.5 OPE Ass’y
5-11
5.6 Side Cover Ass’y
5-12
5.7 Fuser Ass’y
5-14
5.8 Exit Ass'y
5-15
5.9 Cover Paper Exit Ass'y
5-15
5.10 Drive Ass’y
5-16
5.11 SMPS
5-17
5.12 LSU (Laser Scaning Unit)
5-18
5.13 Cover Exit Rear
5-18
5.14 Main Frame Ass’y
5-19
5.15 MP Ass’y
5-20
5.16 Feed Ass’y
5-21
5.17 Pick Up Ass’y
5-22
5.18 Main PBA
5-23
6. Troubleshooting
6.1 Procedure of Checking the Symptoms 6-1
6.2 Solution
6-2
Continued

Samsung SCX 6322DN - B/W Laser - All-in-One Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed	22 ppm
Print Resolution	1200 x 1200 dpi
Copy Resolution	1200 x 1200 dpi
Scan Resolution	600 x 600 dpi
Fax Speed	33.6 Kbps
Automatic Duplex Printing	Yes
Connectivity	USB, Ethernet
Input Capacity	250 sheets
ADF Capacity	50 sheets
Media Size	A4, A5, B5, Letter, Legal
Network Connectivity	Ethernet
USB Connectivity	USB 2.0
Monthly Duty Cycle	50, 000 pages
Operating System Compatibility	Windows, Mac, Linux
