Operating Your Camera
SPECIAL
MAIN SETUP
SSDR ON
WHITE BAL ATW
BACKLIGHT OFF
MOTION DET
OFF
FOCUS
EXPOSURE
SPECIAL
RESET
SPECIAL SETUP
PRIVACY OFF
DAY/NIGHT AUTO
1. Press the SET button to access the main setup menu and then position the indicator over
'SPECIAL' using the UP or DOWN button.
2. Press the SET button to confirm.

PRIVACY : Hide an area you want to hide on the screen.
 When the SPECIAL menu screen is displayed, using the
UP or DOWN button so that the arrow indicates
‘PRIVACY’.
 Set up the mode using the 4 direction buttons.
- AREA SEL : You can select up to 12 areas.
- AREA MODE : Determines whether to use the area selected in the AREA SEL.
- MASK COLOR : Determine area color. You can select Green, Red, Blue, Black, White,
Gray.
PRIVACY SETUP
▶AREA SEL AREA1
AREA MODE ON
MASK COLOR GREEN
TOP 39
BOTTOM 79
LEFT 15
RIGHT 54
RETURN
|||||
|
|||||||||||||||||||
|||||||
|
|||||||||||||||||
|
|||||||||||||||||||||||||
|||||
|
|||||||||||||||||||
SPECIAL SETUP
PRIVACY OFF
DAY/NIGHT AUTO
DIS OFF

DAY/NIGHT : You can display pictures in color or black and white.
 When the SETUP menu screen is displayed, select ‘DAY/NIGHT’ using the UP or
DOWN button so that the arrow indicates 'DAY/NIGHT'.
 Select a desired mode using the LEFT or RIGHT button according to the picture
display you want.
- AUTO : The mode is switched to 'Color' in a normal environment, but switches to 'B/
W' mode when ambient illumination is low. To set up the switching time or
speed for AUTO mode, press the SET button.
- COLOR : The picture is always displayed in color.
- B/W : The picture is always displayed in black and white.
• DWELL TIME : You can select tday/night switching delay
time from.
 5,7,10,15,20,30,40, 60(sec)
• DURATION : You can select the day/night switching
point(lux).
EXT : This mode allows you to apply a desired filter to
external signals.
AUTO SETUP
▶
DWELL TIME 7 SEC
DURATION SLOW
RETURN
BURST MODE SETUP
▶
BURST MODE ON
RETURN
 When AGC is middle mode.
Color → B/W B/W → Color
Fast 2.6Lux 4.2Lux
Slow 1.2Lux 6.0Lux
BURST LEVEL SETUP
▶
BURST LEVEL 50
RETURN
||||||||||||||||||||||
|
