COLOR ZOOM CAMERA User’s Manual
4
COLOR ZOOM CAMERA User’s Manual
5
Contents
Features
Miscellaneous Functions
HLC(HighLightCompensation),SENS-UP,FLIP(H/
V-REV),D-ZOOM,SHARPNESS,MOTION
DETECTIONandPRIVACYfunctionsareprovided.
DAY&NIGHT(ICR)
This camera has a function that automatically
selects the mode that is appropriate for daytime
ornight-timeconditions.
TheCOLORmodeoperatesindaytimeconditions
to provide optimum colors, and BW mode
operatesinnight-timeconditionstoenhancethe
definition of the image.
SSNR 3
(Samsung Super Noise Reduction)
Thehigh-performanceW-VDSPchipeffectively
removeslow-lightgainnoiseandghostingto
provide clear images even in dark environments.
SSDR
(Samsung Super Dynamic Range)
Forimageswithhighcontrastbetweenbright
and dark areas from difficult lighting conditions
such as backlighting, this camera selectively
illuminates darker areas while retaining the
same light level for brighter areas to even out
the overall brightness.
DIS (Digital Image Stabilizer)
TheDISfunctioncompensatesforanycamera
movement, to produce more stable pictures.
Communication
RS-485,Coaxialcommunicationmethodsare
supported.
-RS-485Communications
: SAMSUNG-T,SAMSUNG-E,Pelco-P,Pelco-D,
Vicon, Panasonic,Bosch,Honeywell,AD
-CoaxialCommunications
:PelcoCoaxitron
OSD
Thecamera’sOSDiscomplimentedby18
foreign languages.
-NTSC:Korean,English,French,Spanish,
Japanese,Portuguese,Taiwanese
-PAL:English,French,German,Spanish,
Italian,Chinese,Russian,Czech,Polish,
Portuguese,Romanian,Serbian,
Swedish,Danish,Turkish
• Features ……………………………………………………………… 5
• Warnings & Cautions ………………………………………………… 6
• Precautions…………………………………………………………… 7
• Components and Accessories ……………………………………… 8
• Overview …………………………………………………………… 9
• Connection …………………………………………………………… 11
n ConnectingToMonitor  
 n ConnectingToPower 
 n Connectingto8PControlTerminal  
• Operating Your Camera …………………………………………… 14
n MenuConfiguration  
 n MenuSetup 
·SSDR(SamsungSuperDynamicRange)  
· White Bal (White Balance) 
·BACKLIGHT  
·MotionDetection
·FOCUS 
·EXPOSURE 
·SPECIAL 
·RESET  
·EXIT  
• Troubleshooting ……………………………………………………… 39
• Specifications …………………………………………………………40
• SAMSUNG-T Protocol Command Description …………………… 42
• MEMO ………………………………………………………………… 49
37x Optical Zoom
Thebuilt-inSCZ-2370opticalzoomlensisa
highly durable component. It features auto
focus,autoiris,andzoomfunctions.
Fine Picture Quality under Ultra Low
Lighting
1/4"highdensityCCDallowstheuserto
capturebright,high-qualityimagesunderultra
low lighting conditions.
High Resolution
Featuring600TVlinehorizontalresolutionin
colormodeand700TVlinehorizontalresolutionin
BWmode,thecamerafeaturesSony's410,000
pixelCCDandcapturesclean,noiseless,high-
quality images.
