English _1

English

SAMSUNG ALL-IN-ONE SECURITY SYSTEM

KIT MODEL

SDS-P3042 / V3042/ S3042/ P3022/ P4042 / V4042/

S4042/ P4082/ P5082 / S5082 / P5102 / P5122

DVR MODEL

SDR-3102

/

4102

/

5102

Quick Start Guide

Thank you for purchasing a Samsung DVR Security System.

Follow the simple steps in this guide to set up and start using your new system.

If you have any questions or need help installing your new product please contact our free technical support.

Telephone: 1-877-349-3149

9am - 9pm EST, Monday - Friday

Internet: http://www.samsungsv.com

INSTALLING YOUR SYSTEM

M

 Images may differ depending on the model.

❒

4CH DVR

Front

Rear

1

Connect a mouse

4

Connect the DC adaptors

2

Connect a camera

5

Connect to a network router

3

Connect a monitor

POWER REC NETWORK

1

IN1

IN3

IN4

AUDIO IN

AUDIO OUT

VGA

IN2

HDMI

eSATA

VIDEO IN

LAN

USB

RS485

DC12V

2

3

4

5

Table of Contents

Questions and Answers

P
Patricia GreeneSep 14, 2025
Why do some channels display a black screen on my Samsung SDR-3102?
- R
  rogermilesSep 14, 2025
  If some channels display just a black screen on your Samsung Security System, check if the camera connected to the system properly displays the image and if the camera is properly supplied with power. This problem may also occur on a channel with a weak video signal from a video distributor connected to multiple systems; in this case, input the video source of the camera directly into the DVR.
L
lwilliamsAug 25, 2025
Why is my Samsung DVR not recording?
- M
  Monica MooreAug 25, 2025
  If your player does not display a Live image at all, that indicates recording does not work, so first check if you see an image on the screen. Recording does not work if the recording settings are not properly configured. To start recording manually, press the [REC] button on the remote control. To schedule recording, specify a desired time in Menu – Record – Recording Schedule. Continuous Recording will proceed in any conditions at the specified time. Event Recording will perform only if the event is of alarm, motion detection, video loss and Tampering Detection. If there is no event found, Continuous recording will perform. Whereas, if an event occurs, Event recording will perform.
S
scottkevinAug 25, 2025
How to improve the recording quality on my Samsung DVR?
- H
  hernandezstefanieAug 26, 2025
  To enhance the image quality of your recorded data, increase the resolution and quality level in Menu – Record – Quality / Resolution. You can select a bigger size when specifying the recording size and specify a bigger level for the recording quality.
N
Nicole JohnsonAug 26, 2025
Why can't I play backup data from my Samsung DVR on my PC?
- A
  Anna MeadowsAug 27, 2025
  When you are backing up data, you have choices about the player either: PC or DVR. Make your selection before proceeding. If you are using the PC to play the data, the format of the backup file should be SEC. If you are using the DVR for this purpose, formatting backup files should be done by the DVR.
J
jeffreybarrySep 15, 2025
What to do if the REC button doesn't work on my Samsung SDR-3102 Security System?
- G
  greengregorySep 15, 2025
  If the REC indicator does not flash and the player does not start recording when you press the [REC] button on your Samsung Security System, check if there is free space on the HDD for recording and if the record mode is set to ON in the record mode setting.
J
jessica75Sep 23, 2025
What to do if the ESC key doesn't exit full screen mode in WebViewer on my Samsung SDR-3102 Security System?
- X
  xblackSep 23, 2025
  If pressing the ESC key in full screen mode of the WebViewer on your Samsung Security System does not switch the system to a normal split mode, press the ALT+TAB keys to select ‘ACTIVE MOVIE’ and press the ESC key again.
H
Henry BentleySep 7, 2025
Why is the Channel button not working on my Samsung DVR Live screen?
- J
  Jennifer BeardSep 7, 2025
  The Channel button does not work if the current screen is in the event monitoring mode. Press the [ALARM] button to exit the screen and select a channel.
G
Gregory KingSep 8, 2025
Why can't I move the cursor to the Start button in calendar search on my Samsung DVR?
- M
  Megan WestSep 8, 2025
  Check if the channel and the date that you want to play are marked with the V symbol.
T
Terry WagnerSep 2, 2025
Why doesn't my Samsung DVR recognize all of my external HDDs?
- M
  murphykathySep 2, 2025
  It takes time for the DVR to recognize multiple external HDDs, so try again in a moment. The problem may occur due to a mechanical error of the HDD installed, so try again with a different HDD.
G
garzanathanAug 31, 2025
What does NO HDD icon mean on my Samsung DVR?
- M
  michellesullivanAug 31, 2025
  Check the HDD for connection. If the problem persists in a normal condition, contact the nearest service center to have the HDD checked by the service personnel.
