SAMSUNG ALL-IN-ONE SECURITY SYSTEM

KIT MODEL

SDS-P3042 / V3042/ S3042/ P3022/ P4042 / V4042/

S4042/ P4082/ P5082 / S5082 / P5102 / P5122

DVR MODEL

SDR-3102

/

4102

/

5102

Quick Start Guide

Thank you for purchasing a Samsung DVR Security System.

Follow the simple steps in this guide to set up and start using your new system.

If you have any questions or need help installing your new product please contact our free technical support.

Telephone: 1-877-349-3149

9am - 9pm EST, Monday - Friday

Internet: http://www.samsungsv.com

INSTALLING YOUR SYSTEM

M

 Images may differ depending on the model.

❒

4CH DVR

Front

Rear

1

Connect a mouse

4

Connect the DC adaptors

2

Connect a camera

5

Connect to a network router

3

Connect a monitor

POWER REC NETWORK

1

IN1

IN3

IN4

AUDIO IN

AUDIO OUT

VGA

IN2

HDMI

eSATA

VIDEO IN

LAN

USB

RS485

DC12V

2

3

4

5

Table of Contents

Questions and Answers:

M
mlynchSep 14, 2025
What to do if the [ALARM] button does not release the alarm on my Samsung SDR-5102 Security System?
- C
  Christina MyersSep 14, 2025
  To release the alarm on your Samsung Security System when pressing the [ALARM] button doesn't work, press the [MENU] button and follow these steps: 1) To release the event monitoring mode: Monitoring Mode – set the duration of the event monitoring to Off. 2) To release the alarm sound: Event Record Mode - Alarm (Motion Detection/Video Loss/Tampering Detection) – deactivate the alarm sound. 3) To release the event: Event Record Mode - Alarm (Motion Detection/ Video Loss/Tampering Detection) – set the mode to Off.
E
Eric WarrenAug 25, 2025
Why is my Samsung DVR not recording?
- L
  Larry OliverAug 25, 2025
  If your player does not display a Live image at all, that indicates recording does not work, so first check if you see an image on the screen. Recording does not work if the recording settings are not properly configured. To start recording manually, press the [REC] button on the remote control. To schedule recording, specify a desired time in Menu – Record – Recording Schedule. Continuous Recording will proceed in any conditions at the specified time. Event Recording will perform only if the event is of alarm, motion detection, video loss and Tampering Detection. If there is no event found, Continuous recording will perform. Whereas, if an event occurs, Event recording will perform.
R
Rachel WebbAug 25, 2025
How to improve the recording quality on my Samsung DVR?
- N
  Nichole DavisAug 26, 2025
  To enhance the image quality of your recorded data, increase the resolution and quality level in Menu – Record – Quality / Resolution. You can select a bigger size when specifying the recording size and specify a bigger level for the recording quality.
D
Dawn HarrisAug 26, 2025
Why can't I play backup data from my Samsung DVR on my PC?
- D
  Dr. April Zuniga DDSAug 26, 2025
  When you are backing up data, you have choices about the player either: PC or DVR. Make your selection before proceeding. If you are using the PC to play the data, the format of the backup file should be SEC. If you are using the DVR for this purpose, formatting backup files should be done by the DVR.
C
Corey HughesAug 27, 2025
Why doesn't my Samsung SDR-5102 Security System DVR recognize all the installed HDDs?
- H
  Hannah FloresAug 27, 2025
  If the DVR does not recognize all installed disks when you have connected multiple external HDDs to the Samsung Security System, it may take time for the DVR to recognize them. Try again in a moment. If the problem persists, it may be due to a mechanical error of the HDD installed. Try again with a different HDD.
M
Michele GarzaSep 8, 2025
Why is the time bar missing in Search mode on my Samsung DVR?
- J
  Jacqueline JacksonSep 9, 2025
  The timeline can switch between normal and extension mode. Switch to normal mode or use the left or right button to navigate through the time bar.
S
Samantha HowardSep 7, 2025
Why is the Channel button not working on my Samsung DVR Live screen?
- M
  Melinda RodriguezSep 7, 2025
  The Channel button does not work if the current screen is in the event monitoring mode. Press the [ALARM] button to exit the screen and select a channel.
J
Joshua MartinSep 8, 2025
Why can't I move the cursor to the Start button in calendar search on my Samsung DVR?
- R
  robert82Sep 8, 2025
  Check if the channel and the date that you want to play are marked with the V symbol.
C
crystal06Sep 2, 2025
Why doesn't my Samsung DVR recognize all of my external HDDs?
- L
  lindapearsonSep 2, 2025
  It takes time for the DVR to recognize multiple external HDDs, so try again in a moment. The problem may occur due to a mechanical error of the HDD installed, so try again with a different HDD.
A
Amber LangAug 31, 2025
What does NO HDD icon mean on my Samsung DVR?
- C
  Chad Nguyen PhDAug 31, 2025
  Check the HDD for connection. If the problem persists in a normal condition, contact the nearest service center to have the HDD checked by the service personnel.
