Samsung SF-335T Repair Manual

CIRCUIT DESCRIPTION
3.1.6.3 Decoder Logic Truth Table
nCS HA3 HA2 HA1 HA0 nSTRB5 nSTRB4 nSTRB3 nSTRB2 nSTRB1 nSTRB0 nRx
1 X X X X X X X X X X None
0 X X X X 1 1 1 1 1 1 None
0X000XXXXX 0R26
0X001XXXXX 0R4
0X010XXXXX 0R6
0X011XXXXX 0R8
0X100XXXXX 0R10
0X101XXXXX 0R12
0X110XXXXX 0R14
0X111XXXXX 0R16
00X00XXXX0XR36
00X01XXXX0XR38
00X10XXXX0XR40
00X11XXXX0XR42
01X00XXXX0XR44
01X01XXXX0XR46
01X10XXXX0XR48
01X11XXXX0XR2
0 0 X 0 0 X X X 0 X X R24
0 0 X 0 1 X X X 0 X X R30
0 0 X 1 0 X X X 0 X X R32
0 0 X 1 1 X X X 0 X X R34
0 1 X 0 0 X X X 0 X X R18
0 1 X 0 1 X X X 0 X X R20
0 1 X 1 0 X X X 0 X X R22
0 1 X 1 1 X X X 0 X X R28
0 X 0 0 0 X X 0 X X X R25
0X 0 01X X 0 X X XR3
0X 0 10X X 0 X X XR5
0X 0 11X X 0 X X XR7
0X 1 00X X 0 X X XR9
0X 1 01X X 0 X X XR11
0 X 1 1 0 X X 0 X X X R13
0 X 1 1 1 X X 0 X X X R15
0 0 X 0 0 X 0 X X X X R35
0 0 X 0 1 X 0 X X X X R37
0 0 X 1 0 X 0 X X X X R39
0 0 X 1 1 X 0 X X X X R41
0 1 X 0 0 X 0 X X X X R43
0 1 X 0 1 X 0 X X X X R45
0 1 X 1 0 X 0 X X X X R47
01X11X 0 X X X XR1
01X110XXXXXR27
00X110XXXXXR33
01X010XXXXXR19
00X010XXXXXR29
01X100XXXXXR21
00X100XXXXXR31
01X000XXXXXR17
00X000XXXXXR23
