Exploded view and Part List
3-2
This Document can not be used without Samsung's authorization
3-2. Parts List
Location NO. Description SEC CODE
QRF03 COVER EAR JACK GH72-19702A
QFR01 FRONT GH75-06795A
QMI03 MIC HOLDER GH73-04563A
QVO01 VOLUME KEY GH72-19705A
QSC14 TAPE FRONT HOLE GH74-14197A
QKP01 MEC-KEYPAD GH75-06860A
QME01 UNIT METAL DOME GH59-02045A
QMI01 MICROPHONE ASSY GH30-00199A
QMP01 PBA MAIN GH92-02049A
QVK01 UNIT VOLUME KEY GH59-02067A
QAN02 INTENNA GH42-00557A
QRE01 MEC-REAR COVER GH75-06861A
QIF01 COVER IF CONNECTOR GH72-19704A
QCR06 SCREW-MACHINE 6001-001155
QRF01 RF COVER GH74-14863A
QBA01 BATTERY GH43-01677A
QMW02 WINDOW SUB GH72-19678A
QFU01 UPPER FOLDER GH75-06800A
QLC01 LCD GH07-00680A
QMO01 MOTOR DC GH31-00154D
QSP01 SPEAKER 3001-001759
QCA01 UNIT CAMERA GH59-02098A
QCR05 SCREW-MACHINE 6001-001478
QFR02 OIL DAMPER GH75-06799A
QFL01 FOLDER LOWER GH75-06794A
QCR04 SCREW-MACHINE 6001-001479
QSC01 SCREW CAP GH73-04750A
QMW01 MEC-WINDOW MAIN GH75-06801A
