Samsung SGH-E340 - Speaker Part(Melody)

SAMSUNG Proprietary-Contents may change without notice
Flow Chart of Troubleshooting
This Document can not be used without Samsung's authorization
7-11
7-6. Speaker Part(Melody)
U302 pin 5 = 2.9V?
Speaker does not work
Check the Clock signal at
Pin 1 of U303 (26MHz)
Check the clock generation circuit
(related to U100and U303)
No
Yes
No
Resolder or replace U302
Yes
U303 pin 17,18 ≒ 1.8V?
(When U303 operate)
Resolder U303
No
Yes
END
Is Speaker working?
Change the Speaker
No
Yes
Yes
CN703 pin 40,42 ≒ 1.8V?
(When U303 operate)
Resolder CN703
No
Yes
