Electrical Parts List
4-4
This Document can not be used without Samsung's authorization
SEC CODE Description Design LOC
2203-006208 C-CERAMIC C200 C402 C411
ㅤ C-CERAMIC C413 C417 C421
2203-006257 C-CERAMIC C405 C412 C414
ㅤ C-CERAMIC C415 C423 C424
2203-006562 C-CERAMIC C400 C401 C603
ㅤ C-CERAMIC C607 C613
2404-001225 C-TA C700
2404-001268 C-TA C503
2404-001281 C-TA C422 C600 U704
2404-001348 C-TA C122
2404-001374 C-TA C123 C157 C409
2404-001394 C-TA C150 C309
2703-001938 INDUCTOR-SMD L121
2703-002201 INDUCTOR-SMD L125
2703-002267 INDUCTOR-SMD L124
2703-002346 INDUCTOR-SMD L401
2703-002365 INDUCTOR-SMD L101 L102 L103
ㅤ INDUCTOR-SMD L104
2703-002596 INDUCTOR-SMD L112
2801-004373 CRYSTAL-UNIT OSC400
2809-001294 OSCILLATOR-VCTCXO U102
2901-001286 FILTER-EMI SMD F701 F702 F703
ㅤ FILTER-EMI SMD F704 F705 F706
ㅤ FILTER-EMI SMD F707 F708 F709
2901-001315 FILTER-EMI SMD U502
2911-000007 DUPLEXER-SAW MODULE1
3301-001120 BEAD-SMD L400
3301-001534 BEAD-SMD L600
3705-001358 CONNECTOR-COAXIAL CN101
3709-001355 CONNECTOR-CARD EDGE SIM400
3710-002115 CONNECTOR-SOCKET CN302
3711-005212 CONNECTOR-HEADER CN703
3722-002181 JACK-EAR PHONE CN600
4302-001180 BATTERY BAT401
4709-001371 IC U306
GH13-00029A IC U304
4202-001049 ANTENNA ANT3
GH30-00199A MIC MIC600
