Samsung Electronics 43
8) Disassemble the wire housing of motor in the
center.
9) Pull the housing part and disassemble the wire
terminal.
10) Remove screws of duct and pull apart.
11) Release wire terminal on top of the left.
12) Remove screws of evap. Cover rear and release
the locking part of both left and right using (-)
driver.
latch
Remove 2
screws
Remove 2 screws
To Next Page
