Samsung SR-606EV - In Case of Fan Do Not Run; In Case of Swing Fan in the Refrigerator Doesnt Run

28 Samsung Electronics
1. Swing fan doesn’ t run at the off state of R-fan. ( door closed)
2. Swing fan runs for 30 seconds when the door is open but from then it doesn’ t work as the door
opened continuously. It’ s just runs for 30 seconds from the time the door is opened.
references
Y
N
Swing fan O.K.
Does it run for
30 seconds when the
door open?
N
Y
Change door S/W
Is the door S/W O.K. ?
N
Y
Connection failure
Is the connection of
CON09 O.K. ?
Y
N
Motor failure
Is the vltg of both ends of
motor 220V
Change main PCB ass’ y
Start
9-5 In case of swing fan in the refrigerator doesn’ trun.
