Samsung SyncMaster 3

TABLE OF CONTENTS
INTRODUCTION
FOREWORD
2
FEATURES
2
FCC, IC AND SAFETY INFORMATION
FCC INFORMATlON..
3
IC COMPLIANCE NOTICE
4
WARNING AND CAUTIONS
4
SAFETY TIPS
5
OPERATING GUIDE
CONNECTING TO YOUR COMPUTER 6
CONTROL LOCATIONS AND FUNCTIONS
7
POWER MANAGEMENT SYSTEM
9
SIGNAL CONNECTlONS AND PIN ASSIGNMENT
0
TROUBLESHOOTlNG 11
SPEClFlCATlONS 12
APPENDIX
SIGNAL TIMING CHART 13
Note
— IBM, VGA, XGA, XGA II and PS/2 are registered trademarks of International Business Machines
Corporation
— Super-VGA(SVGA) and VESA are registered trademarks of the Video Electronics Standards Association.
1
