DC OUT
Make sure to use connecting [DC OUT] ter-
minal to the authorized TV-Tuner Box
[SBB_DTC/ZA].
Otherwise, this may result in damage
to the product.
HDMI IN 1
• Connect the [HDMI IN 1] terminal at the
back of your LCD Display to the HDMI
terminal of your digital output device us-
ing a HDMI cable.
• Up to HDMI 1.3 can be supported.
Note
• A normal external device (DVD player or
camcorder, etc.) or a TV tuner box can be
connected to the [HDMI IN 1] terminal.
• To use a TV tuner box, make sure to con-
nect it to the [HDMI IN 1] terminal.
HDMI IN 2 (MAGICINFO)
• Connect the [HDMI IN 2 (MAGICINFO)]
terminal at the back of your LCD Display
to the HDMI terminal of your digital output
device using a HDMI cable.
• Up to HDMI 1.3 can be supported.
Note
Using MagicInfo
• To use MagicInfo with an MXN-3, MPN-3 model,
connect the MagicInfo output on the al-
ready included network box to [HDMI IN
2 (MAGICINFO)] on the product.
• To use MagicInfo with an MX-3,MP-3 model,
install inside the product a network box
specified by Samsung and connect the
MagicInfo output on the network box to
[HDMI IN 2 (MAGICINFO)] on the prod-
uct.
