Header
com-
mand
ID
DATA
Length
Ack/Nak r-CMD Val1
Check
Sum
0xAA 0xFF 3 ‘A’ 0x3D
Auto Ad-
justment
• Nak
Header
com-
mand
ID
DATA
Length
Ack/Nak r-CMD Val1
Check
Sum
0xAA 0xFF 3 ‘N’ 0x3D ERR
ERR : Error code that shows what occurred error is
• Video Wall Mode Control
• Function
Personal Computer converts Video Wall Mode of TV / Monitor when Video Wall is ON.
Only works with TV / Monitor where Video Wall is on.
Does not operate in MagicInfo
• Get Video Wall Mode
Header command
ID
DATA Length
CheckSum
0xAA 0x5C 0
• Set Video Wall Mode
Header command
ID
DATA
Length
DATA
CheckSum
0xAA 0x5C 1 Video Wall
Mode
Video Wall Mode : Video Wall Mode code to be set on TV / Monitor
1 : Full
0 : Natural
•
Ack
Header
com-
mand
ID
DATA
Length
Ack/Nak r-CMD Val1
Check
Sum
0xAA 0xFF 3 ‘A’ 0x5C
Video
Wall
Mode
Video Wall Mode : same as above
