Connecting Using a DVI to HDMI Cable
1. Connect
the DVI output terminal of a digital output device to the [HDMI IN] terminal of
the LCD Display using a DVI to HDMI cable.
2. Connect the red and white jacks of an RCA to stereo (for PC) cable to the same colored
audio output terminals of the digital output device, and connect the opposite jack to the
[AUDIO IN] terminal of the LCD Display.
3. Select HDMI using the SOURCE button on the front of the LCD Display or on the remote
control.
Connecting a DVD Player
1. Connect
a RGB to Component cable between the [RGB / COMPONENT / AV IN] port
on the LCD Display and the P
R
, Y, P
B
jacks on the DVD player.
Connections
38
