Samsung SYNCMASTER 650TS - Connecting Using a HDMI Cable; Connecting Using a DVI to HDMI Cable

Connecting Using a HDMI Cable
1. Connect input devices such as a Blu-Ray/DVD player to the [HDMI IN] terminal of the
LCD Display using an HDMI cable.
2. Select HDMI using the SOURCE button on the front of the LCD Display or on the remote
control.
Note
In HDMI mode, only PCM format audio is supported.
Connecting Using a DVI to HDMI Cable
1. Connect the DVI output terminal of a digital output device to the [HDMI IN] terminal of
the LCD Display using a DVI to HDMI cable.
2. Connect the red and white jacks of an RCA to stereo (for PC) cable to the same colored
audio output terminals of the digital output device, and connect the opposite jack to the
[DVI / RGB / HDMI AUDIO IN] terminal of the LCD Display.
3. Select HDMI using the SOURCE button on the front of the LCD Display or on the remote
control.
Connections
